B8965C

Antennas RF Overview

The TE Connectivity B8965C is a UHF whip antenna designed for the 896 MHz to 970 MHz frequency range, with a center frequency of 933 MHz. It provides a gain of 5 dBi and features a straight mechanical style with an NMO base mount. The antenna supports cellular protocols including GSM, LTE, NB-IoT, and standard cellular applications. It has a maximum power rating of 200 W and a VSWR of 2:1. The unit includes a heavy-duty chrome-plated loading coil with gold contacts to ensure efficient power transfer. The overall length is approximately 13.75 inches (349 mm).

Antennas RF Feature Summary

• Features a straight whip design with an NMO base mount for secure installation.
• Utilizes heavy-duty chrome plating and gold contacts on the loading coil for optimal power transfer.
• Operates within the 896-970 MHz band with 5 dBi gain.
• Supports multiple cellular protocols including GSM, LTE, and NB-IoT.

Antennas RF Applications

• Public Safety communications
• Transportation systems
• Utility grid monitoring
• Military mobile radio applications

Antennas RF Procurement Notes

Verify current availability status as the component may be subject to supply constraints or end-of-life notices depending on the specific manufacturing batch. Confirm that the NMO base mount interface matches the vehicle or equipment mounting hardware. Ensure the operating environment does not exceed the specified power and voltage limits. Check for any recent product change notifications regarding material composition or performance specifications before finalizing procurement orders.

Antennas RF Selection Notes

Select this model when a high-gain UHF antenna is required for vehicles or fixed sites using NMO mounts. It is suitable for applications demanding robust construction with chrome and gold contact materials. Consider the 13.75-inch height for clearance requirements. Compare against lower-gain alternatives if space is limited, though this offers superior performance in the 900 MHz band compared to standard 3 dB models.

Antennas RF Part Context

This component belongs to the TE Connectivity Antenex line of cellular antennas. It is part of a family of UHF whip antennas designed for mobile and fixed radio applications. The B8965C specifically targets the 900 MHz spectrum, distinguishing it from VHF or higher-frequency microwave antennas in the same catalog. It serves as a critical RF interface for transmitting and receiving signals in professional two-way radio networks.

Antennas RF Replacement Considerations

The E8965C is a related model but offers only 3 dB gain and uses a magnetic mount instead of an NMO base. Verify that the mounting interface difference does not preclude direct replacement without adapter hardware. No other direct substitute with identical NMO mounting and 5 dBi gain is publicly confirmed in the provided documentation.
