BDL-123-G-F

Headers, Male Pins Overview

The BDL-123-G-F is a vertical header connector manufactured by Samtec Inc., featuring 46 positions in a double-row configuration. It utilizes a 2.54 mm (0.100 inch) pitch and is designed for through-hole mounting with solder pin termination. The contacts are gold-plated phosphor bronze pins, providing reliable electrical connectivity. The housing is constructed from black nylon insulation, ensuring durability across an operating temperature range of -55°C to +125°C. This component belongs to the BDL series, characterized as a low-profile double-row screw machine terminal strip.

Headers, Male Pins Feature Summary

• Low-profile double-row design optimized for space-constrained board-to-board applications
• Gold-plated phosphor bronze contacts ensure high conductivity and corrosion resistance
• Nylon insulation housing provides mechanical stability and thermal resilience
• Through-hole solder termination supports robust PCB integration

Headers, Male Pins Applications

• Board-to-board interconnections in compact electronic assemblies
• High-density signal routing in industrial control systems
• Interface modules requiring durable vertical header connections

Headers, Male Pins Procurement Notes

Verify the specific ordering suffixes to confirm contact plating and material specifications, as variations exist within the BDL series. Ensure compatibility with mating socket strips such as the SD or SDL series before finalizing procurement. Cross-reference the manufacturer's latest datasheet to confirm current RoHS compliance status and moisture sensitivity levels. Confirm that the through-hole footprint matches the target PCB design requirements.

Headers, Male Pins Selection Notes

Select this component when a low-profile, double-row header is required for vertical interconnection. The gold plating makes it suitable for environments where corrosion resistance is critical. Consider the 46-position count and 2.54 mm pitch to ensure adequate spacing for adjacent components. Verify that the operating temperature range meets the environmental demands of the end application.

Headers, Male Pins Part Context

This part belongs to the BDL series of .100" Low Profile Double Row Screw Machine Terminal Strips. These headers are designed to mate with corresponding socket strips like the SD series. The series offers various position counts and row configurations to support diverse density requirements in modern electronics manufacturing.

Headers, Male Pins Replacement Considerations

Compatible mating connectors include the SD-123-T-F-N and similar .100" double-row socket strips. For direct replacement, verify that the new part maintains the same 46-position count, 2.54 mm pitch, and through-hole mounting style.
