BHR-10-VUA-ML

Headers, Male Pins Overview

The BHR-10-VUA-ML is a male pin header connector from the Adam Tech BHR series, designed for through-hole mounting. It features a 10-position configuration with a single row and a standard .100 inch (2.54mm) centerline pitch. The connector utilizes brass contacts plated with gold flash over nickel underplate to ensure reliable signal transmission. The insulator is constructed from black glass-reinforced PBT material rated UL94V-0, providing structural stability and flame resistance. This component supports an operating voltage of up to 250V AC and a current rating of 1 Amp max.

Headers, Male Pins Feature Summary

• Elevated box header design with plastic insulators to stabilize pin rows for stacking applications
• Low profile construction with snug fit and polarized mating capabilities
• Precision-molded insulators utilizing glass-reinforced PBT for enhanced mechanical strength

Headers, Male Pins Applications

• Stacking applications requiring stabilized pin rows
• General purpose board-to-board interconnections
• Electronic assemblies requiring low profile headers

Headers, Male Pins Procurement Notes

Verify the specific ordering suffix against the manufacturer's official documentation to confirm plating specifications and physical dimensions. Ensure the selected variant matches the required stacking height and PCB tail length for the target application. Cross-reference the part number with the latest datasheet to confirm material ratings and safety agency approvals prior to procurement.

Headers, Male Pins Selection Notes

Select this component when a low profile, polarized header is required for stacking or general interconnection. The BHR series offers straight, right angle, and SMT mounting options. Consider the specific contact plating and insulator material requirements for the operating environment. Verify compatibility with mating sockets and ensure the electrical ratings meet the circuit demands.

Headers, Male Pins Part Context

This component belongs to the Adam Tech BHR Series Elevated Box Headers. The series provides advantages such as low profile design, snug fit, and polarized mating. Additional plastic insulators stabilize rows of pins, making them suitable for stacking applications. The series is available in various mounting styles and configurations to support diverse electronic assembly needs.

Headers, Male Pins Replacement Considerations

Compatible with industry standard .100 inch pitch pin headers. Verify dimensional compatibility and electrical ratings before substituting with other manufacturers' components.
