BWR-15/670-D12A-C

BWR-15/670-D12A-C is listed in the DC DC Converters range at ChipApex. The manufacturer field lists Murata Power Solutions Inc.. Its product description is DC DC CONVERTER +/-15V 20W. Review the specifications below when checking this part for your BOM.

DC DC Converters specifications for BWR-15/670-D12A-C

• Description：DC DC CONVERTER +/-15V 20W
• Series：BWR (10W)
• Mfr：Murata Power Solutions Inc.
• Package：Tube
• Type：Isolated Module
• Number of Outputs：2
• Voltage - Input (Min)：9V
• Voltage - Input (Max)：36V
• Voltage - Output 1：15V
• Voltage - Output 2：-15V
• Voltage - Output 3：-
• Voltage - Output 4：-
• Current - Output (Max)：670mA, 670mA
• Power (Watts)：20 W
• Voltage - Isolation：1 kV
• Applications：ITE (Commercial)
• Features：-
• Operating Temperature：-40°C ~ 100°C
• Efficiency：83%
• Mounting Type：Through Hole
• Package / Case：8-DIP Module, 7 Leads
• Size / Dimension：2.00" L x 2.00" W x 0.45" H (50.8mm x 50.8mm x 11.4mm)
• Supplier Device Package：-
• Control Features：-
• Approval Agency：-
• Standard Number：-

DC DC Converters datasheet and documents for BWR-15/670-D12A-C
