Product Detailed Parameters
- Description：LED COOL WHITE CLR 5MM ROUND T/H
- Series：C535A-WJN
- Mfr：Cree LED
- Package：Bulk
- Color：White, Cool
- Configuration：Standard
- Lens Color：Colorless
- Lens Transparency：Clear
- Millicandela Rating：2640mcd
- Lens Style：Round with Domed Top
- Lens Size：4.80mm Dia
- Voltage - Forward (Vf) (Typ)：3.2V
- Current - Test：20mA
- Viewing Angle：110°
- Mounting Type：Through Hole
- Wavelength - Dominant：9000K
- Wavelength - Peak：-
- Features：-
- Package / Case：Radial
- Supplier Device Package：5mm Round
- Size / Dimension：-
- Height (Max)：6.15mm
- Grade：-
- Qualification：-
Download product information
Overview
The C535A-WJN-CT0W0232 is a cool white emitting LED from Cree LED, designed for through-hole mounting. It features a 5mm round lens with a clear color and surface finish. The component belongs to the C535A-WJN series and utilizes standard leaded construction compliant with ELV Directive 2000/53/EC. This discrete indicator LED provides reliable illumination for electronic status indication applications.
Feature Summary
- Through-hole mounting configuration for secure PCB attachment
- Cool white light emission with clear 5mm round lens
- Standard leaded construction compliant with specific directives
Applications
- Electronic device status indication
- Panel mount power indicators
- General purpose visual signaling
Procurement Notes
Verify component authenticity by cross-referencing the manufacturer part number C535A-WJN-CT0W0232 with official Cree LED documentation. Confirm that the received units match the specified through-hole package and cool white emission characteristics. Ensure compliance requirements regarding lead content are addressed per project specifications before integration.
Selection Notes
Select this component when a through-hole white LED is required for panel or board mounting. The 5mm form factor suits standard drilling patterns. Consider the leaded construction if RoHS exemptions or specific directive compliance are necessary for the target market. Evaluate thermal management needs based on the discrete package type.
Part Context
This part belongs to the C535A-WJN series of discrete LEDs manufactured by Cree LED. The series offers various color and packaging options for general lighting and indication purposes. The C535A-WJN-CT0W0232 specifically denotes the cool white variant in a 5mm through-hole package, distinguishing it from surface-mount or array alternatives within the broader portfolio.
Replacement Considerations
Public confirmed substitute part numbers are not available in the provided source material. Consult official Cree LED catalogs for direct equivalents or functional replacements meeting identical electrical and mechanical specifications.
