CLC406AJM5X
Search Product
Search Post
— IC芯片 | 连接器 | 传感器 | 被动器件 —
Consult the customer manager about the wholesale price.
consultation hotline：86-132-6715-2157
email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.
Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.
Product Detailed Parameters
- Description：IC OPAMP CFA 1 CIRCUIT SOT23-5
- Series：-
- Mfr：Texas Instruments
- Package：Tape & Reel (TR)
- Amplifier Type：Current Feedback
- Number of Circuits：1
- Output Type：-
- Slew Rate：1500V/µs
- Gain Bandwidth Product：-
- Current - Input Bias：5 µA
- Voltage - Input Offset：2 mV
- Current - Supply：5mA
- Current - Output / Channel：-
- Voltage - Supply Span (Min)：5 V
- Voltage - Supply Span (Max)：12 V
- Operating Temperature：-40°C ~ 85°C
- Grade：-
- Qualification：-
- Mounting Type：Surface Mount
- Package / Case：SC-74A, SOT-753
- Supplier Device Package：SOT-23-5
- -3db Bandwidth：160 MHz
Download product information
Overview
The CLC406AJM5X is a wideband, low-power monolithic operational amplifier manufactured by Texas Instruments. It is designed for applications requiring high speed with minimal power consumption and cost. The device utilizes a current feedback architecture to achieve superior performance in low-gain configurations. It is housed in a compact SOT-23-5 package, facilitating integration into space-constrained designs. The component operates within a standard industrial temperature range, ensuring reliability across various electronic systems.
Feature Summary
- Current feedback topology provides high slew rate and wide bandwidth
- Optimized for low gain applications to minimize power usage
- Compact SOT-23-5 surface-mount package for space efficiency
Applications
- Video signal processing circuits
- High-speed data acquisition systems
- Portable battery-powered equipment
Procurement Notes
Verify the specific suffix 'JM5X' against the official datasheet to confirm pinout and electrical characteristics match your design requirements. Ensure the component meets all environmental and safety standards required for your final product assembly before procurement.
Selection Notes
Select this component when a wideband amplifier is needed for low-gain applications where power dissipation is critical. The current feedback structure offers advantages over voltage feedback amplifiers in terms of stability and speed at higher frequencies. Evaluate the SOT-23-5 footprint constraints during the PCB layout phase.
Part Context
This part belongs to the CLC406 series of wideband operational amplifiers. It is distinct from voltage-feedback counterparts due to its current-feedback architecture, which typically offers faster settling times and reduced sensitivity to gain-bandwidth trade-offs in non-inverting configurations.
Replacement Considerations
Consult official substitution guides for compatible current-feedback amplifiers. Verify that any alternative maintains the same SOT-23-5 package dimensions and electrical specifications to ensure seamless integration without redesigning the printed circuit board.
