DCM713U063DF2B

DCM713U063DF2B is listed in the Aluminum Electrolytic Capacitors range at ChipApex. The manufacturer field lists Cornell Dubilier Knowles. Its product description is CAP ALUM 71000UF 63V SCREW CHAS. Review the specifications below when checking this part for your BOM.

Aluminum Electrolytic Capacitors specifications for DCM713U063DF2B

• Description：CAP ALUM 71000UF 63V SCREW CHAS
• Series：DCM
• Mfr：Cornell Dubilier Knowles
• Package：Bulk
• Capacitance：71000 µF
• Tolerance：-10%, +75%
• Voltage - Rated：63 V
• ESR (Equivalent Series Resistance)：-
• Lifetime @ Temp.：2000 Hrs @ 85°C
• Operating Temperature：-40°C ~ 85°C
• Polarization：Polar
• Ratings：-
• Applications：General Purpose
• Ripple Current @ Low Frequency：-
• Ripple Current @ High Frequency：-
• Lead Spacing：1.250" (31.75mm)
• Size / Dimension：3.000" Dia (76.20mm)
• Height - Seated (Max)：5.687" (144.45mm)
• Surface Mount Land Size：-
• Mounting Type：Chassis Mount
• Package / Case：Radial, Can - Screw Terminals

Aluminum Electrolytic Capacitors datasheet and documents for DCM713U063DF2B
