DF14A-15P-1.25H(54)

Headers, Male Pins Overview

The DF14A-15P-1.25H(54) is a Hirose Electric shrouded header connector featuring 15 positions in a single row with a 1.25 mm pitch. Designed for surface mount right-angle installation, it utilizes male pin contacts made of brass with gold plating. The housing is constructed from brown polyamide (PA) rated UL 94 V-0. It supports a maximum current of 1 A and operates within a temperature range of -35°C to +85°C.

Headers, Male Pins Feature Summary

• Shrouded four-wall housing design provides mechanical protection and alignment for mating connections.
• Right-angle surface mount termination facilitates compact board layout integration.
• Gold-plated brass contacts ensure reliable signal transmission and corrosion resistance.

Headers, Male Pins Applications

• Wire-to-board interconnections
• Electronic module assembly
• Consumer electronics internal wiring

Headers, Male Pins Procurement Notes

Verify component authenticity through authorized distributors or direct manufacturer channels. Confirm RoHS compliance status via official documentation. Check for obsolescence notices as the part may be discontinued. Ensure storage conditions maintain integrity before soldering.

Headers, Male Pins Selection Notes

Select this model for applications requiring right-angle SMT headers with a 1.25 mm pitch. Verify that the 15-position count matches circuit requirements. Ensure compatibility with mating wire harnesses or female connectors designed for the DF14 series.

Headers, Male Pins Part Context

This component belongs to the Hirose DF14 series, which offers various position counts and packaging options. It is specifically engineered for high-density electronic assemblies where space efficiency and secure connection reliability are critical design factors.

Headers, Male Pins Replacement Considerations

DF14A-15P-1.25H(65)
