DSGP.1575.18.2.A.02

$7.58

Description：RF ANT 1.575GHZ CER PATCH SLD
Series：-
Mfr：Taoglas Limited
Package：Tape & Reel (TR),Cut Tape (CT)

SKU:212bb7540939 Category: RF Antennas Brand: Taoglas Limited

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

DSGP.1575.18.2.A.02 is listed in the Antennas RF range at ChipApex. The manufacturer field lists Taoglas Limited. Its product description is RF ANT 1.575GHZ CER PATCH SLD. Review the specifications below when checking this part for your BOM.

Antennas RF specifications for DSGP.1575.18.2.A.02

Description：RF ANT 1.575GHZ CER PATCH SLD
Series：-
Mfr：Taoglas Limited
Package：Tape & Reel (TR),Cut Tape (CT)
RF Family/Standard：Navigation
Frequency Group：UHF (1GHz ~ 2GHz)
Frequency (Center/Band)：1.575GHz
Frequency Range：1.574GHz ~ 1.576GHz
Antenna Type：Ceramic Patch
Number of Bands：1
VSWR：2:01
Return Loss：-10dB
Gain：2.4dBi
Features：-
Termination：Solder
Ingress Protection：-
Grade：-
Qualification：-
Mounting Type：Surface Mount
Height (Max)：0.079" (2.00mm)
Applications：Galileo, GPS
Power - Max：-

Antennas RF datasheet and documents for DSGP.1575.18.2.A.02

DSGP.1575.18.2.A.02

Antennas RF Overview

The DSGP.1575.18.2.A.02 is a ceramic patch RF antenna manufactured by Taoglas Limited, designed for Global Positioning System (GPS) and Galileo navigation applications. It operates at the standard L1 frequency of 1.575GHz with a narrow bandwidth ranging from 1.574GHz to 1.576GHz. The component provides a gain of 2.4dBi and utilizes a solder surface mount installation type. Its physical dimensions are 18mm x 18mm x 2mm, ensuring a compact form factor suitable for space-constrained electronic devices requiring precise satellite signal reception.

Antennas RF Feature Summary

Supports dual-band operation for GPS L1 and Galileo E1 signals
Constructed using durable ceramic patch technology
Features a low-profile surface mount design for PCB integration

Antennas RF Applications

GPS navigation modules
Galileo positioning systems
GNSS receiver integration

Antennas RF Procurement Notes

Verify the specific suffix configuration against the manufacturer's official datasheet to ensure compatibility with target assembly processes. Confirm that the solder surface mount termination matches the intended PCB footprint and reflow profile requirements. Cross-reference the RoHS compliance status with current environmental regulations applicable to the deployment region prior to finalizing procurement orders.

Antennas RF Selection Notes

Select this component when a compact, high-precision ceramic patch solution is required for L1 band satellite navigation. The 18x18mm footprint offers a balance between performance and board space efficiency. Ensure the application environment does not require wideband capabilities beyond the specified 1.574GHz to 1.576GHz range, as this model is optimized for narrowband GNSS reception rather than multi-standard cellular or broadband data transmission.

Antennas RF Part Context

This part belongs to the DSGP.1575.18 series of GNSS antennas from Taoglas Limited. It is specifically engineered for satellite navigation systems, distinguishing it from broader cellular or general-purpose RF antennas in the manufacturer's portfolio. The series focuses on providing reliable signal acquisition for positioning applications using standard ceramic materials.
