FBNAB3100ZF110

Power Line Filter Modules Overview

The KEMET FBNAB3100ZF110 is a single-phase IEC power line filter designed for chassis or panel mounting. It features a rated voltage of 250 VAC at 50/60 Hz and supports a continuous current of 6 A. The unit incorporates common mode inductance of 1 mH per line and includes an integrated X-class capacitor with a capacitance value of 0.1 µF. This configuration provides electromagnetic interference suppression for AC power inputs.

Power Line Filter Modules Feature Summary

• Integrates common mode chokes and X-capacitors for EMI filtering
• Supports chassis or panel mounting configurations
• Complies with IEC safety standards

Power Line Filter Modules Applications

• AC power input stages for electronic equipment
• Industrial control systems requiring EMI suppression
• Medical device power supplies

Power Line Filter Modules Procurement Notes

Verify the specific datasheet version to confirm exact dimensional tolerances and terminal configurations. Ensure the mounting hardware matches the chassis thickness. Confirm that the operating environment temperature remains within the specified range during installation.

Power Line Filter Modules Selection Notes

Select this component when a compact, single-phase solution is required for 250 VAC circuits. The 6 A rating suits moderate power loads. Verify that the 1 mH inductance meets the specific noise attenuation requirements of the application circuit.

Power Line Filter Modules Part Context

This part belongs to the KEMET FBN series of IEC power line filters. These components are engineered for general-purpose electromagnetic interference reduction in AC power lines. The series offers standardized ratings for easy integration into various electrical enclosures.

Power Line Filter Modules Replacement Considerations

Public confirmed substitute part numbers are not available in the provided documentation.
