FC100V20A-G

Power Line Filter Modules Overview

The FC100V20A-G is a single-stage AC EMC/EMI line filter manufactured by Bel Power Solutions. It features a three-phase star configuration and is rated for 20 A current with a 100 V DC voltage rating. The component utilizes through-hole PC pin termination for mounting. It operates within a temperature range of -40°C to +100°C and is designated for general-purpose applications.

Power Line Filter Modules Feature Summary

• Provides electromagnetic interference suppression in three-phase power circuits
• Utilizes single-stage filtering architecture for noise reduction
• Designed for through-hole printed circuit board integration

Power Line Filter Modules Applications

• General-purpose industrial equipment power conditioning
• Three-phase AC power line noise filtration
• Electromagnetic compatibility enhancement in electronic systems

Power Line Filter Modules Procurement Notes

Verify component status as the FC100V20A-G is listed as obsolete or discontinued by multiple distributors. Confirm availability of alternative sources or equivalent replacement parts from Bel Power Solutions before initiating procurement processes. Ensure design updates accommodate end-of-life management protocols.

Power Line Filter Modules Selection Notes

Select this component for three-phase applications requiring 20 A filtering capacity. Verify that the 100 V DC rating aligns with system requirements. Consider the through-hole mounting style and operating temperature range when evaluating suitability for specific enclosure environments and thermal constraints.

Power Line Filter Modules Part Context

This part belongs to the FC series of power line filters from Bel Power Solutions. It is categorized under passive components, specifically EMI/EMC filters. The product is designed for AC input lines, providing attenuation of conducted emissions to meet regulatory standards in industrial and commercial settings.

Power Line Filter Modules Replacement Considerations

Publicly confirmed substitute part numbers are not available in the provided documentation. As the FC100V20A-G is marked as obsolete, consult Bel Power Solutions directly for current equivalent models or recommended alternatives within their updated portfolio.
