FLLDU200A225I0

Power Line Filter Modules Overview

The KEMET FLLDU200A225I0 is a single-phase EMC power line filter rated for 250 VAC and 440 VDC with a continuous current capacity of 200 A. It features a capacitance of 1 µF per phase and utilizes an M32 metric nut for chassis mounting. The unit operates within a temperature range of -40 °C to +85 °C and complies with UL and IEC/EN standards.

Power Line Filter Modules Feature Summary

• Provides high-current electromagnetic interference suppression for single-phase applications
• Utilizes threaded post termination for secure mechanical integration
• Designed for robust chassis mounting in industrial environments

Power Line Filter Modules Applications

• Industrial motor drive input filtering
• Power conversion systems requiring high current handling
• Heavy machinery power supply conditioning

Power Line Filter Modules Procurement Notes

Verify the specific voltage rating requirements against the datasheet, as variants exist for different AC voltages. Confirm the terminal type matches the installation hardware, specifically the M32 metric nut specification. Ensure the ambient operating temperature remains within the specified -40 °C to +85 °C range during deployment.

Power Line Filter Modules Selection Notes

Select this component when high continuous current ratings near 200 A are required alongside effective EMI attenuation. Compare physical dimensions and mounting constraints against available panel space. Evaluate thermal management needs given the high current load and potential heat generation under full operational stress.

Power Line Filter Modules Part Context

This component belongs to the KEMET FLLD series of feed-through power line filters. These units are engineered for demanding industrial power conditions, offering reliable noise reduction while maintaining structural integrity under high electrical loads and rigorous environmental conditions.

Power Line Filter Modules Replacement Considerations

Cross-reference part numbers such as FLLDU300A026I0 for higher current requirements or FLLDU200A225I0 variants with different voltage ratings. Verify that substitute models maintain identical mounting interfaces and capacitance values to ensure system compatibility.
