FLLE2020AUDI

Power Line Filter Modules Overview

The KEMET FLLE2020AUDI is a single-phase EMI filter designed for chassis mounting. It supports a maximum current of 20 A and operates at voltages up to 300 V AC/DC with a frequency range of 50-60 Hz. The unit features a two-stage configuration utilizing threaded M4 terminals. Key electrical parameters include an inductance of 2,700 uH and a capacitance of 10 nF. Physical dimensions are 130.5 mm in length, 56.5 mm in width, and 48.5 mm in height. The device functions within a temperature range of -25°C to +100°C.

Power Line Filter Modules Feature Summary

• Two-stage noise suppression architecture for enhanced attenuation
• Chassis mount design with self-extinguishing resin filled metal case
• Threaded M4 terminal connections for secure installation

Power Line Filter Modules Applications

• Industrial power supply units
• Medical equipment power inputs
• General purpose electronic systems requiring EMC compliance

Power Line Filter Modules Procurement Notes

Verify the specific ordering suffix against official KEMET documentation to ensure correct terminal type and certification requirements. Confirm that the rated voltage and current specifications align with the target application's electrical demands. Check for RoHS compliance status and relevant safety certifications such as UL or ENEC before finalizing procurement decisions.

Power Line Filter Modules Selection Notes

Select this component when a single-phase filter with high attenuation is required for chassis-mounted applications. Ensure the physical footprint fits the enclosure constraints due to its specific dimensional profile. Verify that the operating temperature range meets environmental conditions and that the 20 A current rating provides sufficient margin for peak loads.

Power Line Filter Modules Part Context

This part belongs to the FLLE2-U series of general-purpose single-phase EMI filters. The series offers various current ratings and termination options, including fast-on tabs and flexible wires. The FLLE2020AUDI specifically utilizes threaded posts, distinguishing it from other variants in the family that may use different connection methods.

Power Line Filter Modules Replacement Considerations

Consult official KEMET substitution guides for direct replacements. Cross-reference similar models within the FLLE2-U series if terminal types differ. Verify that any substitute maintains identical electrical ratings and physical dimensions to ensure compatibility.

Power Line Filter Modules FAQ

What is the inductance value of the FLLE2020AUDI?

The inductance is 2,700 uH.

Does this filter support DC voltage input?

Yes, it is rated for up to 300 V DC.
