FM51OM1013

FM51OM1013 is listed in the Antennas RF range at ChipApex. The manufacturer field lists Fairview Microwave. Its product description is ANTENNA TYPE N JACK 824 MHZ-960. Review the specifications below when checking this part for your BOM.

Antennas RF specifications for FM51OM1013

• Description：ANTENNA TYPE N JACK 824 MHZ-960
• Series：-
• Mfr：Fairview Microwave
• Package：Bag
• RF Family/Standard：Cellular, General ISM
• Frequency Group：UHF (300MHz ~ 1GHz)
• Frequency (Center/Band)：892MHz
• Frequency Range：824MHz ~ 960MHz
• Antenna Type：Whip, Straight
• Number of Bands：1
• VSWR：1.5
• Return Loss：-
• Gain：3dBi
• Features：Cable - 305mm, Cable - 1.524m, Cable - 3.048m, Cable - 7.62m
• Termination：N Type Female
• Ingress Protection：-
• Grade：-
• Qualification：-
• Mounting Type：Bracket Mount
• Height (Max)：12.300" (312.42mm)
• Applications：GSM, IoT, ISM, LoRa, LPWAN, M2M
• Power - Max：100 W

Antennas RF datasheet and documents for FM51OM1013
