FTM-130-03-L-DV

Headers, Male Pins Overview

The Samtec FTM-130-03-L-DV is a surface mount header featuring 60 positions across two rows with a 1.00 mm pitch. It utilizes phosphor bronze contacts with light gold plating and matte tin tails, housed in black liquid crystal polymer. Designed for board-to-board connections, it offers a 2.8 A current rating per contact and operates within a -55°C to 125°C temperature range.

Headers, Male Pins Feature Summary

• Micro low profile design optimized for space-constrained applications
• Flexible positioning allows configurations up to 100 I/Os
• Available with or without end shrouds and guide posts
• Supports pick-and-place assembly processes

Headers, Male Pins Applications

• Board-to-board interconnects in compact electronic modules
• High-density signal routing in telecommunications equipment
• Industrial control systems requiring reliable surface mount headers

Headers, Male Pins Procurement Notes

Verify the specific suffix requirements against the official Samtec FTM series print before ordering. Confirm whether the application requires the standard lead style or the extended post height indicated by the '-03' designation. Ensure the selected packaging matches production needs, as tape and reel options may require distinct part number suffixes compared to tube packaging.

Headers, Male Pins Selection Notes

Select this component when a 1.00 mm pitch surface mount header is required for high-density layouts. The 'L' plating specification provides cost-effective gold coverage suitable for general signal transmission. Consider the 'DV' configuration for dual-wipe mating compatibility if using CLM sockets. Validate thermal performance against the 125°C maximum operating limit during system integration.

Headers, Male Pins Part Context

This part belongs to the FTM series of 1.00 mm micro low profile terminal strips. It is designed for surface mount technology and mates with various Samtec socket strips. The series supports flexible position counts and optional shrouding, making it a versatile solution for modern PCB architectures requiring reliable, low-profile connectivity.

Headers, Male Pins Replacement Considerations

FTM-130-03-L-DV-P-TR: Identical electrical specifications but packaged in tape and reel format for automated assembly. FTM-130-03-G-DV-P: Features heavy gold plating instead of light gold for enhanced durability.
