IXD2142A30DER-G

Voltage Regulators - DC DC Switching Regulators Overview

The IXD2142A30DER-G is a step-up DC-DC converter manufactured by Zilog, classified under Switching Voltage Regulators within the PMIC category. It features an integrated load disconnect function and operates with a fixed switching frequency of 3.0 MHz. The device supports auto-switching between PFM and PWM modes to optimize efficiency across varying load conditions. Designed for compact applications, it delivers up to 0.8 A output current. The component is supplied in a reel packaging format.

Voltage Regulators - DC DC Switching Regulators Feature Summary

• Integrates a load disconnect function for system power management
• Supports automatic switching between PFM and PWM operation modes
• Operates at a fixed 3.0 MHz switching frequency

Voltage Regulators - DC DC Switching Regulators Applications

• Portable electronic devices requiring efficient step-up conversion
• Battery-powered systems utilizing load disconnect capabilities
• Compact power management circuits in consumer electronics

Voltage Regulators - DC DC Switching Regulators Procurement Notes

Verify the manufacturer designation as Zilog when sourcing this component. Confirm the specific suffix DER-G corresponds to the required package and tape-and-reel configuration. Ensure compatibility with the 3.0 MHz switching frequency requirement for your design. Cross-reference the datasheet for thermal and electrical limits before integration.

Voltage Regulators - DC DC Switching Regulators Selection Notes

Select this model when a step-up converter with integrated load disconnect is required. The 3.0 MHz frequency allows for smaller passive components compared to lower-frequency alternatives. Choose this variant over the C-series if higher switching speed is necessary for your application constraints.

Voltage Regulators - DC DC Switching Regulators Part Context

This part belongs to the IXD2142 series of step-up DC-DC converters from Zilog. It shares functional similarities with other variants like the IXD2142B30DER-G but differs in specific operational parameters or package types. The series is designed for portable applications requiring efficient power management and compact footprints.

Voltage Regulators - DC DC Switching Regulators Replacement Considerations

The IXD2142B30DER-G is a related variant within the same product family. Verify pinout and parameter compatibility before substitution. Other IXD2142 series parts may serve as alternatives depending on specific frequency or package requirements.
