L513LBGW-S

LED Indication - Discrete Overview

The L513LBGW-S is a single-color surface-mount LED manufactured by American Opto Plus LED. It features a blue-green light emission with a dominant wavelength of 505nm and a typical forward voltage of 3.5V. The component utilizes a white, diffused lens to provide a viewing angle of 40 degrees. Designed for board-level integration, this device offers uniform light output suitable for various electronic applications requiring precise color specification.

LED Indication - Discrete Feature Summary

• Blue-green light emission with a dominant wavelength of 505nm
• White diffused lens for controlled light distribution
• Surface-mount package design for automated assembly

LED Indication - Discrete Applications

• Board-level indicator lighting
• Electronic status signaling
• Automotive qualified display modules

LED Indication - Discrete Procurement Notes

Verify the specific manufacturing lot date code against project requirements before procurement. Confirm that the 505nm dominant wavelength aligns with optical design specifications. Ensure compatibility with standard reflow soldering profiles for surface-mount technology. Check for any recent updates in RoHS compliance documentation from the manufacturer.

LED Indication - Discrete Selection Notes

Select this component when a distinct blue-green hue is required for visual indicators. The 40-degree viewing angle provides focused illumination compared to wider-angle alternatives. Consider the 3.5V forward voltage drop when designing current-limiting resistor networks. Evaluate the white diffused lens option if glare reduction is necessary for the application environment.

LED Indication - Discrete Part Context

American Opto Plus LED specializes in high-quality board-level LEDs and backlight products. Founded in 1973, the company holds ISO 9002 certification and produces various LED lamps, displays, and SMD components. This part belongs to their range of single-color surface-mount devices designed for reliable performance in consumer and industrial electronics.

LED Indication - Discrete Replacement Considerations

No public confirmed substitute part numbers are available in the provided documentation. Cross-reference electrical parameters such as forward voltage and peak wavelength carefully when evaluating alternative manufacturers.
