M22-2010946

Headers, Male Pins Overview

The M22-2010946 is a vertical pin header from the Harwin M22 series, designed for board-to-board connections. It features 9 positions with a 2.00mm (0.079 inch) pitch and a 2.00mm row spacing. The connector utilizes phosphor bronze contacts with gold plating for reliable signal transmission. It supports through-hole termination and operates within a temperature range of -55°C to +105°C. The housing is constructed from black PA6T nylon rated UL94 V-0 for flame resistance.

Headers, Male Pins Feature Summary

• Vertical orientation facilitates compact board stacking
• Gold-plated phosphor bronze contacts ensure durability
• High-temperature resistant PA6T insulation material

Headers, Male Pins Applications

• Board-to-board interconnects in industrial equipment
• Signal routing in consumer electronics assemblies
• Internal connections in automotive control modules

Headers, Male Pins Procurement Notes

Verify the specific contact count and plating thickness against the official datasheet before integration. Confirm that the vertical height and pitch align with the target PCB layout constraints. Ensure compatibility with mating sockets within the same M22 series family to maintain mechanical integrity.

Headers, Male Pins Selection Notes

Select this component when a low-profile vertical header with high-temperature stability is required. The 2.00mm pitch allows for dense circuit layouts while maintaining adequate clearance. Consider the gold plating for applications requiring frequent mating cycles or corrosion resistance compared to tin variants.

Headers, Male Pins Part Context

This part belongs to the M22 series, known for its robust construction and versatile mounting options. The series offers various configurations including right-angle and horizontal headers. The M22-2010946 specifically addresses needs for vertical insertion with precise 9-position alignment in space-constrained designs.

Headers, Male Pins Replacement Considerations

Compatible substitutes include other Harwin M22 series headers with matching 2.00mm pitch and 9 positions, such as M22-2010905 (tin plated) or M22-2010948 (different contact length). Verify mechanical dimensions and electrical ratings before substitution.
