M22-2410542

Headers, Male Pins Overview

The M22-2410542 is a Harwin M22 series header connector featuring 10 positions in a dual-row configuration with a 2mm pitch. Designed for board-to-board applications, it utilizes gold and tin plated contacts on phosphor bronze terminals to ensure reliable electrical performance. The component supports through-hole mounting in a right-angle orientation, allowing for efficient PCB layout space utilization. It operates within a temperature range of -40°C to +105°C and is housed in nylon insulation.

Headers, Male Pins Feature Summary

• Dual-row pin header design facilitates high-density interconnections between printed circuit boards.
• Right-angle orientation enables compact vertical stacking and optimized spatial arrangement on the PCB.
• Gold and tin contact plating options provide enhanced corrosion resistance and stable signal transmission.

Headers, Male Pins Applications

• Board-to-board interconnection systems requiring right-angle mounting
• Industrial control modules with limited vertical clearance
• Consumer electronics assemblies utilizing dense PCB layouts

Headers, Male Pins Procurement Notes

Verify the specific contact plating configuration required for your application, as the datasheet indicates gold and tin options. Confirm that the right-angle through-hole footprint matches your PCB design constraints. Ensure compatibility with mating connectors from the same M22 series family to maintain mechanical integrity and electrical specifications.

Headers, Male Pins Selection Notes

Select this component when a right-angle connection is necessary to save horizontal board space. The dual-row format allows for increased pin count within a narrow width profile. Consider the operating temperature range and current carrying capacity requirements to ensure the phosphor bronze contacts meet the system's electrical demands without overheating.

Headers, Male Pins Part Context

This part belongs to the Harwin M22 series, which offers various configurations including single and double rows with different pin counts. The series is known for its robust construction and suitability for demanding industrial environments. Other variants in the series may differ in row count, orientation, or plating materials while maintaining the standard 2mm pitch.

Headers, Male Pins Replacement Considerations

Direct substitutes must match the 10-position, dual-row, right-angle specification with a 2mm pitch. Verify that any alternative connector maintains the same through-hole mounting style and compatible housing material properties to ensure proper fit and function.
