M22-2410646

Headers, Male Pins Overview

The M22-2410646 is a male pin header from the Harwin M22 series, designed for board-to-board connections. It features a 2 mm pitch and a 12-position configuration arranged in two rows. The connector utilizes a right-angle through-hole solder termination style with tin-plated phosphor bronze contacts housed in black nylon. Rated for 500 VAC voltage and 2 A current, it operates within a temperature range of -40°C to +105°C. The unit weighs approximately 3.398 grams.

Headers, Male Pins Feature Summary

• Right-angle shrouded design for secure board mounting
• Tin-plated phosphor bronze contacts for reliable conductivity
• Nylon housing with UL 94 V-0 flammability rating

Headers, Male Pins Applications

• Board-to-board interconnects
• Industrial control systems
• Consumer electronics assemblies

Headers, Male Pins Procurement Notes

Verify component availability status as this part number is listed as obsolete or end-of-life by major distributors. Confirm if replacement stock exists or if alternative sourcing channels are required. Ensure compatibility with mating sockets before procurement, as lead times may vary significantly for remaining inventory.

Headers, Male Pins Selection Notes

Select this component when a right-angle, dual-row header with a 2 mm pitch is required. Verify that the application environment stays within the specified -40°C to +105°C operating range. Ensure the PCB layout accommodates the specific footprint dimensions and that the 2 A current rating meets the circuit requirements.

Headers, Male Pins Part Context

This component belongs to the M22 series of connectors manufactured by Harwin Inc. The series is characterized by its compact form factor and high-density capabilities. The M22-2410646 specifically represents a 12-position variant within this family, offering a standardized solution for space-constrained electronic designs requiring robust mechanical stability.

Headers, Male Pins Replacement Considerations

Public sources indicate this part is obsolete. Potential substitutes include similar right-angle headers from the same manufacturer or compatible alternatives with matching 2 mm pitch and 12-position specifications.
