M22-2511146

Description：CONN HEADER VERT 11POS 2MM
Series：M22
Mfr：Harwin Inc.
Package：Bulk

SKU:19bfeee5c03b Category: Headers, Male Pins Brand: Harwin Inc.

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

M22-2511146 is listed in the Headers, Male Pins range at ChipApex. The manufacturer field lists Harwin Inc.. Its product description is CONN HEADER VERT 11POS 2MM. Review the specifications below when checking this part for your BOM.

Headers, Male Pins specifications for M22-2511146

Description：CONN HEADER VERT 11POS 2MM
Series：M22
Mfr：Harwin Inc.
Package：Bulk
Connector Type：Header, Cuttable
Contact Type：Male Pin
Pitch - Mating：0.079" (2.00mm)
Number of Positions：11
Number of Rows：1
Row Spacing - Mating：-
Number of Positions Loaded：All
Style：Board to Board
Shrouding：Unshrouded
Mounting Type：Through Hole
Termination：Solder
Fastening Type：Push-Pull
Contact Length - Mating：0.138" (3.50mm)
Contact Length - Post：0.091" (2.30mm)
Overall Contact Length：0.287" (7.30mm)
Insulation Height：0.059" (1.50mm)
Contact Shape：Square
Contact Finish - Mating：Tin
Contact Finish Thickness - Mating：-
Contact Finish - Post：Tin
Contact Material：Phosphor Bronze
Insulation Material：Polyamide (PA6T), Nylon 6T
Features：-
Operating Temperature：-40°C ~ 105°C
Ingress Protection：-
Material Flammability Rating：UL94 V-0
Insulation Color：Black
Current Rating (Amps)：1A per Contact
Voltage Rating：-

Headers, Male Pins datasheet and documents for M22-2511146

M22-2511146

Headers, Male Pins Overview

The Harwin M22-2511146 is a rectangular header connector from the M22 series, designed for board-to-board interconnections. It features 11 positions with a 2.00mm (0.079 inch) pitch and utilizes single-row male pin contacts. The component supports through-hole termination and employs a push-pull locking mechanism for secure mating. Constructed with phosphor bronze contacts featuring gold plating and a black polyamide (PA6T) insulator, it operates within a temperature range of -40°C to 105°C and meets UL94 V-0 flammability standards.

Headers, Male Pins Feature Summary

Push-pull locking system ensures secure mechanical retention during mating cycles
Gold-plated phosphor bronze contacts provide reliable conductivity and corrosion resistance
High-temperature resistant PA6T insulation supports demanding thermal environments

Headers, Male Pins Applications

Board-to-board interconnects in industrial control systems
Signal transmission in automotive electronic modules
Connections in telecommunications infrastructure equipment

Headers, Male Pins Procurement Notes

Verify the specific ordering suffix against the official Harwin datasheet to confirm contact length and terminal orientation. Ensure compatibility with mating socket components regarding pitch and locking style. Confirm RoHS3 compliance status if required by project specifications before finalizing procurement orders.

Headers, Male Pins Selection Notes

Select this connector when a 2.00mm pitch header with push-pull retention is required for high-reliability applications. Consider the single-row configuration and through-hole mounting constraints during PCB layout. Evaluate the operating temperature range and current carrying capacity against system requirements to ensure long-term performance stability.

Headers, Male Pins Part Context

This component belongs to the Harwin M22 series, which offers various configurations including different row counts, pitches, and locking mechanisms. The M22 series is widely used in harsh environment applications requiring robust mechanical and electrical performance. This specific part represents a standard 11-position variant within that extensive family.
