M22-2531005

Headers, Male Pins Overview

The M22-2531005 is a pin header connector from the Harwin M22 series, designed for board-to-board applications. It features a single row of ten male pins with a 2mm (0.079 inch) pitch. The connector utilizes through-hole straight termination and is constructed with phosphor bronze contacts that have a gold plating finish. The housing is made of black nylon 6T material, rated UL94 V-0 for flammability. It operates within a temperature range of -40°C to +105°C and supports a voltage rating of 500V.

Headers, Male Pins Feature Summary

• Single-row configuration with ten male contact positions
• Through-hole straight termination style for PCB mounting
• Gold-plated phosphor bronze contacts for reliable conductivity
• Black nylon 6T insulation with UL94 V-0 flammability rating

Headers, Male Pins Applications

• Board-to-board interconnections in electronic assemblies
• High-density circuit board stacking applications
• Industrial control system signal routing
• Consumer electronics internal connectivity

Headers, Male Pins Procurement Notes

Verify the specific part number against official Harwin documentation to confirm current production status and availability. Ensure compatibility with mating sockets regarding pitch and row count. Check for RoHS compliance requirements if applicable to your manufacturing standards. Confirm storage conditions to maintain contact integrity before assembly.

Headers, Male Pins Selection Notes

Select this component when a single-row, ten-position header is required for vertical PCB mounting. The 2mm pitch offers a balance between density and spacing. Consider the through-hole method for robust mechanical fixation. Evaluate the 500V rating and 1A per contact capacity against circuit requirements. Ensure the operating temperature range suits the environmental conditions.

Headers, Male Pins Part Context

This connector belongs to the M22 series, known for high-density interconnect solutions. The series provides various configurations including right-angle and surface mount options. The M22-2531005 specifically addresses needs for straight, through-hole mounting in compact designs. It complements other M22 series components for complete system integration.

Headers, Male Pins Replacement Considerations

Direct substitutes may include other Harwin M22 series headers with identical pin count and pitch. Verify mechanical dimensions and electrical ratings before substitution. Cross-reference with compatible mating sockets from the same manufacturer to ensure proper engagement.
