M22-5300405

$0.92

Description：CONN HEADER SMD 8POS 2MM
Series：M22
Mfr：Harwin Inc.
Package：Tube

SKU:15d321c43c2d Category: Headers, Male Pins Brand: Harwin Inc.

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

M22-5300405 is listed in the Headers, Male Pins range at ChipApex. The manufacturer field lists Harwin Inc.. Its product description is CONN HEADER SMD 8POS 2MM. Review the specifications below when checking this part for your BOM.

Headers, Male Pins specifications for M22-5300405

Description：CONN HEADER SMD 8POS 2MM
Series：M22
Mfr：Harwin Inc.
Package：Tube
Connector Type：Header, Cuttable
Contact Type：Male Pin
Pitch - Mating：0.079" (2.00mm)
Number of Positions：8
Number of Rows：2
Row Spacing - Mating：0.079" (2.00mm)
Number of Positions Loaded：All
Style：Board to Board
Shrouding：Unshrouded
Mounting Type：Surface Mount
Termination：Solder
Fastening Type：Push-Pull
Contact Length - Mating：0.138" (3.50mm)
Contact Length - Post：-
Overall Contact Length：-
Insulation Height：0.059" (1.50mm)
Contact Shape：Square
Contact Finish - Mating：Gold
Contact Finish Thickness - Mating：Flash
Contact Finish - Post：-
Contact Material：Phosphor Bronze
Insulation Material：Polyamide (PA6T), Nylon 6T
Features：Board Guide
Operating Temperature：-40°C ~ 105°C
Ingress Protection：-
Material Flammability Rating：UL94 V-0
Insulation Color：Black
Current Rating (Amps)：1A per Contact
Voltage Rating：-

Headers, Male Pins datasheet and documents for M22-5300405

M22-5300405

Headers, Male Pins Overview

The Harwin M22-5300405 is a surface mount header connector featuring eight male pins arranged in a double-row configuration with a 2.00mm pitch. Constructed from black polyamide insulation and phosphor bronze contacts, it utilizes a push-pull locking mechanism for secure mating. The component supports a working temperature range of -40°C to 105°C and meets UL94 V-0 flammability standards. Designed for board-to-board applications, it offers a contact length of 3.50mm and an insulation height of 1.50mm.

Headers, Male Pins Feature Summary

Double-row SMT pin header design with integrated location pegs
Push-pull locking system for reliable mechanical retention
Gold-plated phosphor bronze contacts for signal integrity
High-temperature resistant polyamide insulation material

Headers, Male Pins Applications

Board-to-board interconnections
High-reliability electronic assemblies
Surface mount manufacturing processes

Headers, Male Pins Procurement Notes

Verify the specific suffix against official datasheets to confirm exact plating thickness and packaging type. Ensure compatibility with automated pick-and-place equipment due to the surface mount footprint. Confirm that the push-pull latch mechanism aligns with the target assembly's mechanical constraints before finalizing procurement orders.

Headers, Male Pins Selection Notes

Select this component when a robust, high-density connection is required for vertical board stacking. The double-row layout maximizes pin count within a minimal footprint while maintaining standard 2.00mm spacing. Consider the push-pull latching feature if vibration resistance and secure mating are critical operational requirements.

Headers, Male Pins Part Context

This part belongs to the Harwin M22 series, which specializes in high-reliability connectors for demanding environments. The series is characterized by its modular design, allowing for various row configurations and termination styles. The M22-5300405 specifically addresses needs for compact, vertically mounted connections in space-constrained electronic designs.
