Headers, Male Pins Overview

Harwin M22-5320446 is a surface mount header connector from the M22 series, featuring an 8-position single-row configuration with a 2.00mm (0.079 inch) pitch. The component utilizes phosphor bronze contacts with gold plating for reliable signal transmission. It employs a polyamide (PA6T) insulation material rated UL94 V-0 for fire resistance and operates within a temperature range of -40°C to +105°C. Designed for high-density PCB applications, this male pin header supports automated pick-and-place assembly processes.

Headers, Male Pins Feature Summary

• Surface mount technology compatible with automated SMT assembly lines
• Gold-plated phosphor bronze contacts ensure stable electrical conductivity
• High-temperature resistant PA6T insulation meets UL94 V-0 safety standards

Headers, Male Pins Applications

• High-density board-to-board interconnections
• Automated surface mount electronics manufacturing
• Compact consumer electronic device assemblies

Headers, Male Pins Procurement Notes

Verify the specific contact finish thickness and mating length specifications against the official Harwin datasheet before integration. Confirm that the surface mount footprint aligns precisely with your PCB design requirements. Ensure compatibility with standard reflow soldering profiles suitable for PA6T materials. Cross-reference the exact part number suffix to confirm the correct packaging format and quantity per reel.

Headers, Male Pins Selection Notes

Select this model when space constraints require a low-profile, surface-mounted solution with a 2mm pitch. It is suitable for designs needing robust thermal stability and reliable signal integrity in compact form factors. Consider the single-row layout for simplified routing compared to dual-row alternatives. Evaluate the gold plating benefits against cost constraints for critical signal paths.

Headers, Male Pins Part Context

The M22-5320446 belongs to Harwin's M22 family, known for fine-pitch connectivity solutions. This series addresses modern demands for miniaturization while maintaining industrial-grade reliability. The component represents a balance between high connection density and ease of automated manufacturing, fitting into broader system architectures requiring precise spatial efficiency.

Headers, Male Pins Replacement Considerations

M22-5320446P serves as a documented variant within the same series offering similar functional characteristics.
