M22-5330505

Headers, Male Pins Overview

The M22-5330505 is a rectangular connector header from the Harwin M22 series, designed for surface mount applications. It features a right-angle configuration with five positions and a 2.00mm (0.079 inch) mating pitch. The connector utilizes gold-plated contacts made from phosphor bronze to ensure reliable electrical performance. It is rated for 1A per contact and operates within a temperature range of -40°C to 105°C. The housing is constructed from black polyamide (PA6T), meeting UL94 V-0 flammability standards. This single-row component is intended for board-to-board or cable connections.

Headers, Male Pins Feature Summary

• Surface mount right-angle design for compact PCB integration
• Gold-plated phosphor bronze contacts for enhanced conductivity
• High-temperature resistant PA6T insulation material
• Single-row configuration with cuttable format

Headers, Male Pins Applications

• Board-to-board interconnections in dense electronic assemblies
• Cable-to-board connections requiring right-angle routing
• Industrial control systems operating in high-temperature environments
• Automotive electronics modules

Headers, Male Pins Procurement Notes

Verify that the specific part number M22-5330505 matches the required surface mount right-angle configuration and five-position count. Confirm compatibility with the mating socket series, such as the M22-6xx series, ensuring correct pin count and orientation. Check datasheets for precise soldering profile requirements and reflow compatibility with the PA6T housing material.

Headers, Male Pins Selection Notes

Select this component when a low-profile, right-angle surface mount header is required for five circuits. The 2.00mm pitch offers a balance between density and spacing. Ensure the application environment stays within the -40°C to 105°C operational range. Consider the cuttable nature of the header if variable position counts are needed across different production runs.

Headers, Male Pins Part Context

This component belongs to the Harwin M22 series, which provides industrial-standard connectors with a 2.00mm pitch. The series includes various configurations for through-hole and surface mount installations. The M22-5330505 specifically addresses needs for right-angle surface mounting, offering a robust solution for modern PCB designs where space efficiency and thermal stability are critical factors.

Headers, Male Pins Replacement Considerations

Compatible mating sockets include the M22-6330505 (SMT) and M22-7330505 (Through-Hole). Verify that substitute parts maintain the same 2.00mm pitch, five-position count, and right-angle orientation to ensure mechanical and electrical compatibility.
