M40-3011546

Headers, Male Pins Overview

The Harwin M40-3011546 is a surface-mount board-to-board connector header from the M40 series. It features 15 positions with a 1.00 mm (0.039 inch) pitch. The component utilizes a single row of vertical male pins designed for SMT assembly. It is constructed with phosphor bronze contacts and gold plating to ensure reliable electrical performance in high-density interconnect applications.

Headers, Male Pins Feature Summary

• Vertical surface-mount design for compact PCB integration
• Single row configuration with 15 contact positions
• Gold-plated phosphor bronze contacts for durability

Headers, Male Pins Applications

• High-density electronic assemblies requiring small form factors
• Industrial control systems with space-constrained layouts
• Communication equipment utilizing board-to-board interconnects

Headers, Male Pins Procurement Notes

Verify that the specific part number matches the required 15-position, 1.00mm pitch specification. Confirm RoHS compliance status and lead-free requirements against project standards. Ensure the vertical SMT orientation aligns with the mechanical layout constraints of the target printed circuit board design before finalizing procurement orders.

Headers, Male Pins Selection Notes

Select this component when a low-profile, single-row header is required for direct surface mounting. The 1.00 mm pitch allows for higher density compared to standard 2.54 mm headers. Consider the vertical orientation for mating with corresponding sockets or cables without protruding laterally from the board edge.

Headers, Male Pins Part Context

This connector belongs to the Harwin M40 family, which specializes in fine-pitch interconnect solutions. The series is engineered for applications demanding robust connections in limited spaces. The M40-3011546 represents a standard vertical header variant within this lineup, offering compatibility with other components in the same pitch ecosystem.

Headers, Male Pins Replacement Considerations

No publicly confirmed substitute part numbers are available in the provided documentation. Verify pin count and pitch compatibility if considering alternative manufacturers.
