M50-3202645

Headers, Receptacles, Female Sockets Overview

The Harwin M50-3202645 is a double-row surface mount socket connector from the Archer M50 series. It features 26 positions (10+10) with a 1.27 mm pitch and operates at 1 A current rating. The contacts are gold-plated phosphor bronze, housed in black liquid crystal polymer (LCP). Designed for horizontal PCB installation, it offers UL 94 V-0 flammability and functions within a -40°C to +105°C range.

Headers, Receptacles, Female Sockets Feature Summary

• Double-row surface mount architecture for compact board integration
• Gold-plated phosphor bronze contacts ensuring reliable conductivity
• Liquid crystal polymer housing providing high thermal stability

Headers, Receptacles, Female Sockets Applications

• Wire-to-board interconnections
• Board-to-board connections
• High-density electronic assemblies

Headers, Receptacles, Female Sockets Procurement Notes

Verify the specific suffix against official Harwin documentation to confirm exact pin count and termination style. Ensure compatibility with automated SMT placement equipment. Cross-reference the datasheet for precise footprint dimensions and reflow soldering profiles before finalizing procurement orders.

Headers, Receptacles, Female Sockets Selection Notes

Select this component for applications requiring high-density double-row connectivity with surface mount technology. Verify that the 1.27 mm pitch aligns with the target PCB design. Confirm that the LCP material properties meet the environmental requirements of the intended operating temperature range.

Headers, Receptacles, Female Sockets Part Context

This part belongs to the Harwin Archer M50 series, designed for high-reliability interconnect solutions. The series supports various configurations including IDC, through-hole, and surface mount options. The M50-3202645 specifically addresses needs for compact, robust double-row sockets in space-constrained electronics.

Headers, Receptacles, Female Sockets Replacement Considerations

Consult official Harwin substitution guides for verified alternatives. Generic equivalents may not match the precise 1.27 mm pitch or LCP material specifications required for proper fit and thermal performance.
