M50-3600342

Headers, Male Pins Overview

The Harwin M50-3600342 is a male pin header from the ARCHER M50 series, designed for surface-mount technology (SMT) applications. It features a 1.27 mm pitch with two rows and six contacts. The connector utilizes gold-plated phosphor bronze terminals housed in a black thermoplastic insulator rated UL94 V-0. Rated for 1A current and 250V voltage, it operates within a temperature range of -55°C to +105°C. The unshrouded design facilitates streamlined board-to-board or wire-to-board connections.

Headers, Male Pins Feature Summary

• Surface-mount termination for automated PCB assembly
• Gold-plated phosphor bronze contacts for reliable conductivity
• Unshrouded dual-row architecture for compact integration

Headers, Male Pins Applications

• Board-to-board interconnections
• Wire-to-board assemblies
• High-density electronic modules

Headers, Male Pins Procurement Notes

Verify the specific manufacturer part number against official Harwin documentation to confirm contact count and row configuration. Ensure compatibility with SMT reflow profiles and mating connector specifications. Cross-reference terminal plating thickness and insulation material ratings against project requirements before procurement.

Headers, Male Pins Selection Notes

Select this component for applications requiring low-profile surface-mount headers with precise 1.27 mm spacing. Consider the unshrouded design constraints regarding adjacent components. Verify that the 1A current rating and 250V voltage limit align with circuit demands. Confirm mechanical fit within the designated PCB footprint.

Headers, Male Pins Part Context

This component belongs to the ARCHER M50 series by Harwin Inc., a line of high-reliability connectors known for precision engineering. The series supports various mounting styles and contact configurations, catering to diverse industrial and consumer electronics needs. The M50-3600342 specifically addresses the need for compact, solderable interconnect solutions.

Headers, Male Pins Replacement Considerations

Public confirmed substitute part numbers are not available in the provided source data. Consult Harwin technical support or authorized distributors for verified cross-reference information.
