M50-3930842

$0.48

Description：CONN HEADER R/A 8POS 1.27MM
Series：Archer M50
Mfr：Harwin Inc.
Package：Box

SKU:d687357bf04a Category: Headers, Male Pins Brand: Harwin Inc.

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

M50-3930842 is listed in the Headers, Male Pins range at ChipApex. The manufacturer field lists Harwin Inc.. Its product description is CONN HEADER R/A 8POS 1.27MM. Review the specifications below when checking this part for your BOM.

Headers, Male Pins specifications for M50-3930842

Description：CONN HEADER R/A 8POS 1.27MM
Series：Archer M50
Mfr：Harwin Inc.
Package：Box
Connector Type：Header
Contact Type：Male Pin
Pitch - Mating：0.050" (1.27mm)
Number of Positions：8
Number of Rows：1
Row Spacing - Mating：-
Number of Positions Loaded：All
Style：Board to Board or Cable
Shrouding：Unshrouded
Mounting Type：Through Hole, Right Angle
Termination：Solder
Fastening Type：Push-Pull
Contact Length - Mating：0.157" (4.00mm)
Contact Length - Post：0.094" (2.40mm)
Overall Contact Length：-
Insulation Height：0.039" (1.00mm)
Contact Shape：Square
Contact Finish - Mating：Gold
Contact Finish Thickness - Mating：-
Contact Finish - Post：Tin
Contact Material：Brass
Insulation Material：Polyamide (PA9T), Nylon 9T
Features：-
Operating Temperature：-40°C ~ 105°C
Ingress Protection：-
Material Flammability Rating：UL94 V-0
Insulation Color：Black
Current Rating (Amps)：1A per Contact
Voltage Rating：-

Headers, Male Pins datasheet and documents for M50-3930842

M50-3930842

Headers, Male Pins Overview

The M50-3930842 is a Harwin ARCHER series single-row header connector with an 8-position configuration. It features a 1.27 mm pitch and utilizes gold-plated phosphor bronze contacts housed in black polyamide (PA). Designed for surface-mount technology, it offers right-angle installation with a straight orientation relative to the board edge. The component supports a maximum current of 1 A and operates within a temperature range of -40°C to +105°C, meeting UL 94 V-0 flammability standards.

Headers, Male Pins Feature Summary

Single-row surface-mount architecture for compact PCB integration
Gold-plated phosphor bronze contacts ensuring reliable signal transmission
Right-angle design facilitating efficient spatial utilization on circuit boards

Headers, Male Pins Applications

High-density electronic assemblies requiring space-efficient connections
Consumer electronics utilizing surface-mount manufacturing processes
Industrial control systems needing robust 1.27mm pitch interconnects

Headers, Male Pins Procurement Notes

Verify the specific suffix codes against official Harwin documentation to confirm exact plating thickness and material specifications. Ensure compatibility with automated pick-and-place equipment due to the surface-mount package type. Cross-reference the UL 94 V-0 rating with system safety requirements before finalizing procurement decisions.

Headers, Male Pins Selection Notes

Select this component when a single-row, right-angle surface-mount header is required for 1.27mm pitch applications. Consider the 1A current rating and -40°C to +105°C operating range for environmental suitability. Verify that the polyamide housing and gold contact finish align with the target application's corrosion resistance and electrical performance needs.

Headers, Male Pins Part Context

This part belongs to the ARCHER M50 series, a comprehensive line of rectangular connectors from Harwin. The series is characterized by its fine 1.27mm pitch and diverse mounting options, including through-hole and surface-mount variants. The M50-3930842 specifically addresses the need for compact, high-reliability interconnects in modern electronics manufacturing.
