M50-3932042

Headers, Male Pins Overview

The Harwin M50-3932042 is a 20-position single-row pin header from the Archer M50 series. It features a 1.27 mm pitch and right-angle through-hole mounting for board-to-board or wire-to-board connections. The connector utilizes gold-plated phosphor bronze contacts rated for 1A current. Constructed with a black polyamide (PA) housing, it operates within a temperature range of -40°C to +105°C and meets UL 94 V-0 flammability standards.

Headers, Male Pins Feature Summary

• Right-angle design facilitates compact vertical interconnections
• Gold-plated phosphor bronze contacts ensure reliable signal transmission
• Polyamide housing provides thermal stability and flame resistance

Headers, Male Pins Applications

• Board-to-board interconnects in industrial control systems
• Wire-to-board connections in consumer electronics
• Signal routing in automotive electronic modules

Headers, Male Pins Procurement Notes

Verify the specific contact configuration and housing color against official datasheets before procurement. Confirm that the right-angle orientation matches the PCB layout requirements. Ensure compatibility with mating connectors within the same M50 series family to guarantee proper mechanical engagement and electrical performance.

Headers, Male Pins Selection Notes

Select this component when a low-profile, right-angle connection is required for dense circuit layouts. The 1.27 mm pitch suits applications needing high I/O density. Consider the through-hole termination method for robust mechanical anchoring. Evaluate the 1A current rating against the specific circuit load requirements to ensure safe operation under all expected conditions.

Headers, Male Pins Part Context

This part belongs to the Archer M50 series, designed for high-density interconnect solutions. The series offers various row counts and orientations to support diverse assembly needs. The M50-3932042 specifically addresses single-row applications requiring right-angle termination.

Headers, Male Pins Replacement Considerations

Compatible substitutes include other Harwin M50 series headers with matching 1.27 mm pitch and 20 positions. Verify identical right-angle orientation and through-hole termination style. Ensure equivalent current ratings and material specifications for direct replacement.
