M50-4304045

Headers, Receptacles, Female Sockets Overview

The Harwin M50-4304045 is a surface-mount board-to-board receptacle from the Archer M50 series. It features a dual-row configuration with 40 positions and a 1.27mm pitch. The connector utilizes gold-plated contacts for reliable signal transmission. Designed for high-density applications, it offers a compact profile suitable for space-constrained electronic assemblies requiring robust interconnection.

Headers, Receptacles, Female Sockets Feature Summary

• Surface-mount technology implementation for automated assembly
• Dual-row architecture supporting high pin count density
• Gold contact plating to ensure corrosion resistance and conductivity

Headers, Receptacles, Female Sockets Applications

• High-density board-to-board interconnections
• Compact electronic device assembly
• Automated surface-mount production lines

Headers, Receptacles, Female Sockets Procurement Notes

Verify the specific datasheet for the M50-4304045 to confirm exact mechanical dimensions and mating partner requirements. Ensure compatibility with standard reflow soldering profiles. Cross-reference official Harwin documentation for precise handling instructions and storage conditions to maintain component integrity prior to installation.

Headers, Receptacles, Female Sockets Selection Notes

Select this component when a low-profile, dual-row SMT solution is required for 1.27mm pitch applications. Consider the 40-position capacity relative to available PCB real estate. Verify that the mating header matches the series specifications to ensure proper alignment and electrical continuity within the system design constraints.

Headers, Receptacles, Female Sockets Part Context

This part belongs to the Harwin Archer M50 family, known for its reliability in demanding environments. The M50 series provides various configurations including shrouded and unshrouded options. This specific model represents a standard receptacle variant optimized for direct surface mounting on printed circuit boards.

Headers, Receptacles, Female Sockets Replacement Considerations

Consult Harwin's official cross-reference guides for verified substitutes. Generic equivalents may not match the precise mechanical tolerances or material specifications of the original component.
