M50-4801745

Headers, Male Pins Overview

The M50-4801745 is a rectangular connector header from the Harwin Archer M50 series. It features a vertical through-hole mounting style with male pin contacts. The connector provides 34 positions arranged in a dual inline configuration, utilizing a 0.050-inch (1.27mm) pitch. The housing is constructed from black liquid crystal polymer and includes shrouding for alignment. This component is designed for board-to-board or cable applications.

Headers, Male Pins Feature Summary

• Vertical orientation for through-hole PCB integration
• Shrouded housing design for precise mating alignment
• Male pin contact type for socket compatibility

Headers, Male Pins Applications

• Board-to-board interconnections
• Cable-to-board connections
• General electronic equipment assembly

Headers, Male Pins Procurement Notes

Verify current availability status as this part number may be obsolete. Confirm mechanical dimensions and contact plating specifications against the official datasheet to ensure compatibility with existing designs. Check for end-of-life notifications or recommended replacement parts from the manufacturer before finalizing procurement plans.

Headers, Male Pins Selection Notes

Select this component when a vertical, shrouded header with male pins is required for 1.27mm pitch applications. Ensure the mating socket supports the specific contact geometry and current ratings defined for the Archer M50 series. Validate that the through-hole footprint matches the specified pin layout and insulation height requirements.

Headers, Male Pins Part Context

This connector belongs to the Harwin Archer M50 family, which offers various configurations including surface-mount and IDC options. The series is known for high-density interconnect solutions in compact electronic assemblies. The M50-4801745 specifically represents a legacy vertical through-hole variant within this extensive product line.

Headers, Male Pins Replacement Considerations

Public sources indicate this part is obsolete. Verify if Harwin has issued a formal discontinuation notice. Identify equivalent active parts from the same series or compatible third-party alternatives that match the 34-position, 1.27mm pitch, vertical through-hole specification.
