MA624S-05ERU

MA624S-05ERU is listed in the DC DC Converters range at ChipApex. The manufacturer field lists MicroPower Direct. Its product description is DC/DC,6W,24V IN,5V OUT,1.5KV,. Review the specifications below when checking this part for your BOM.

DC DC Converters specifications for MA624S-05ERU

• Description：DC/DC,6W,24V IN,5V OUT,1.5KV,
• Series：MA600ERU
• Mfr：MicroPower Direct
• Package：Tube
• Type：Isolated Module
• Number of Outputs：1
• Voltage - Input (Min)：9V
• Voltage - Input (Max)：36V
• Voltage - Output 1：5V
• Voltage - Output 2：-
• Voltage - Output 3：-
• Voltage - Output 4：-
• Current - Output (Max)：1.2A
• Power (Watts)：6 W
• Voltage - Isolation：1.5 kV
• Applications：Industrial, ITE (Commercial)
• Features：OCP, Proportional Output
• Operating Temperature：-40°C ~ 85°C
• Efficiency：83%
• Mounting Type：Through Hole
• Package / Case：-
• Size / Dimension：1.26" L x 0.79" W x 0.43" H (32.0mm x 20.0mm x 10.8mm)
• Supplier Device Package：-
• Control Features：Enable, Active High
• Approval Agency：CE, cURus, UKCA
• Standard Number：62368-1
• Grade：-
• Qualification：-

DC DC Converters datasheet and documents for MA624S-05ERU
