MAL225035472E3

MAL225035472E3 is listed in the Aluminum Electrolytic Capacitors range at ChipApex. The manufacturer field lists Vishay Beyschlag/Draloric/BC Components. Its product description is CAP ALUM 4700UF 20% 16V RADIAL. Review the specifications below when checking this part for your BOM.

Aluminum Electrolytic Capacitors specifications for MAL225035472E3

• Description：CAP ALUM 4700UF 20% 16V RADIAL
• Series：250 RMI-V
• Mfr：Vishay Beyschlag/Draloric/BC Components
• Package：Box
• Capacitance：4700 µF
• Tolerance：±20%
• Voltage - Rated：16 V
• ESR (Equivalent Series Resistance)：-
• Lifetime @ Temp.：10000 Hrs @ 105°C
• Operating Temperature：-55°C ~ 105°C
• Polarization：Polar
• Ratings：AEC-Q200
• Applications：Audio, Automotive
• Ripple Current @ Low Frequency：2.196 A @ 100 Hz
• Ripple Current @ High Frequency：2.89 A @ 100 kHz
• Lead Spacing：0.295" (7.50mm)
• Size / Dimension：0.709" Dia (18.00mm)
• Height - Seated (Max)：1.063" (27.00mm)
• Surface Mount Land Size：-
• Mounting Type：Through Hole
• Package / Case：Radial, Can
• Impedance：19 mOhms

Aluminum Electrolytic Capacitors datasheet and documents for MAL225035472E3
