MAX20402AFLB/VY+T

Voltage Regulators - DC DC Switching Regulators Overview

The MAX20402AFLB/VY+T is a synchronous step-down switching regulator from the MAX2040x family, designed for high-efficiency power conversion. It operates with an input voltage range of 3V to 36V and delivers a continuous output current of 2.5A. The device features an adjustable output voltage starting from 0.8V up to 12V. It integrates a 2.1MHz fixed-frequency PWM controller and utilizes a compact 15-pin FC2QFN package measuring 3mm x 3mm. Certified to AEC-Q100 standards, it supports automotive applications with an operating temperature range of -40°C to +125°C.

Voltage Regulators - DC DC Switching Regulators Feature Summary

• Integrated synchronous rectification for enhanced efficiency across load ranges
• Fixed 2.1MHz switching frequency enabling compact passive component selection
• Automotive-grade qualification ensuring reliability in harsh environments
• Compact footprint design facilitating dense PCB layout

Voltage Regulators - DC DC Switching Regulators Applications

• Automotive infotainment systems requiring stable low-voltage rails
• Industrial control boards needing isolated or non-isolated DC-DC conversion
• Embedded computing platforms utilizing 12V or 24V bus architectures

Voltage Regulators - DC DC Switching Regulators Procurement Notes

Verify the specific suffix 'VY+T' corresponds to the tape-and-reel packaging format required for automated assembly processes. Confirm that the FLB variant matches the intended thermal and electrical specifications for the target application environment. Ensure compliance with RoHS directives as indicated by the plus sign in the part number. Cross-reference the manufacturer's latest documentation to validate current production status and availability constraints.

Voltage Regulators - DC DC Switching Regulators Selection Notes

Select this component when a 2.5A output current is sufficient for the load requirements within a 36V maximum input constraint. The 2.1MHz switching frequency offers a balance between size and efficiency compared to lower frequency alternatives. Consider the 15-pin FC2QFN package dimensions if board space is limited. Verify that the external inductor and capacitor values align with the internal compensation network for stable operation at the desired output voltage.

Voltage Regulators - DC DC Switching Regulators Part Context

This device belongs to the MAX2040x series of high-voltage synchronous buck converters. It shares architectural similarities with the MAX20403 but differs in output current capability and pin configuration. The series targets applications requiring robust performance from high-input voltage sources down to standard logic levels.

Voltage Regulators - DC DC Switching Regulators Replacement Considerations

The MAX20402AFLE/VY+ is a tray-packaged equivalent offering identical electrical characteristics. For higher current needs, the MAX20403AFLB/VY+T provides 3A output capability within the same package family.
