MPM-04S-03

MPM-04S-03 is listed in the AC DC Converters range at ChipApex. The manufacturer field lists MicroPower Direct. Its product description is AC/DC MODULE ,4W, 3.3V OUT. Review the specifications below when checking this part for your BOM.

AC DC Converters specifications for MPM-04S-03

• Description：AC/DC MODULE ,4W, 3.3V OUT
• Series：MPM-04V (4W)
• Mfr：MicroPower Direct
• Package：Box
• Type：Open Frame
• Number of Outputs：1
• Voltage - Input：90 ~ 264 VAC, 120 ~ 370 VDC
• Voltage - Output 1：3.3V
• Voltage - Output 2：-
• Voltage - Output 3：-
• Voltage - Output 4：-
• Current - Output (Max)：1.2A
• Applications：Industrial, ITE (Commercial)
• Features：Universal Input
• Operating Temperature：-40°C ~ 70°C
• Efficiency：-
• Mounting Type：Chassis Mount
• Package / Case：-
• Size / Dimension：1.44" L x 1.06" W x 0.67" H (36.5mm x 26.9mm x 17.0mm)
• Approval Agency：CE, UR
• Standard Number：60950
• Power (Watts)：-

AC DC Converters datasheet and documents for MPM-04S-03
