MPM-10C-03

MPM-10C-03 is listed in the AC DC Converters range at ChipApex. The manufacturer field lists MicroPower Direct. Its product description is AC/DC MODULE, 5W, 3V OUT. Review the specifications below when checking this part for your BOM.

AC DC Converters specifications for MPM-10C-03

• Description：AC/DC MODULE, 5W, 3V OUT
• Series：MPM-10SV (10W)
• Mfr：MicroPower Direct
• Package：Box
• Type：Open Frame
• Number of Outputs：1
• Voltage - Input：85 ~ 305 VAC, 100 ~ 430 VDC
• Voltage - Output 1：3.3V
• Voltage - Output 2：-
• Voltage - Output 3：-
• Voltage - Output 4：-
• Current - Output (Max)：2.6A
• Applications：Industrial, ITE (Commercial)
• Features：Universal Input
• Operating Temperature：-40°C ~ 85°C
• Efficiency：-
• Mounting Type：Chassis Mount
• Package / Case：-
• Size / Dimension：1.58" L x 1.00" W x 0.83" H (40.0mm x 25.4mm x 21.0mm)
• Approval Agency：CE, cURus, UKCA
• Standard Number：62368-1
• Power (Watts)：-

AC DC Converters datasheet and documents for MPM-10C-03
