MPM-40S-12

MPM-40S-12 is listed in the AC DC Converters range at ChipApex. The manufacturer field lists MicroPower Direct. Its product description is AC/DC MODULE ,40W, 12V OUT. Review the specifications below when checking this part for your BOM.

AC DC Converters specifications for MPM-40S-12

• Description：AC/DC MODULE ,40W, 12V OUT
• Series：MPM-40
• Mfr：MicroPower Direct
• Package：Box
• Type：Enclosed
• Number of Outputs：1
• Voltage - Input：90 ~ 264 VAC, 100 ~ 375 VDC
• Voltage - Output 1：12V
• Voltage - Output 2：-
• Voltage - Output 3：-
• Voltage - Output 4：-
• Current - Output (Max)：3.333A
• Applications：Industrial, ITE (Commercial)
• Features：-
• Operating Temperature：-40°C ~ 70°C
• Efficiency：84%
• Mounting Type：Through Hole
• Package / Case：-
• Size / Dimension：3.50" L x 2.50" W x 0.98" H (89.0mm x 63.5mm x 25.0mm)
• Approval Agency：CE, UR
• Standard Number：60950
• Power (Watts)：40 W

AC DC Converters datasheet and documents for MPM-40S-12
