MS121-00000U-500PG

Pressure Sensors Transducers Overview

The MS121-00000U-500PG is an industrial pressure sensor manufactured by TE Connectivity / Measurement Specialties. It features a Microfused design with a 500 psi gauge pressure range and a 1/4-18 NPT process connection. The device provides a 0 to 100 mV analog output signal, powered by a 5 V supply voltage. It operates within a temperature range of -40 °C to +125 °C and offers an accuracy of 0.25%. The unit weighs approximately 100.5 g and measures 80.14 mm in length.

Pressure Sensors Transducers Feature Summary

• Microfused construction for robust industrial performance
• Ratiometric analog output signal capability
• High accuracy measurement specification
• Direct cable mount installation configuration

Pressure Sensors Transducers Applications

• Industrial process control systems
• Hydraulic and pneumatic monitoring
• Automotive testing equipment
• Aerospace instrumentation

Pressure Sensors Transducers Procurement Notes

Verify the specific part number suffix against official TE Connectivity documentation to ensure correct pressure rating and interface specifications. Confirm that the required operating temperature range aligns with the component's rated limits. Check for any specific environmental certifications or compliance requirements relevant to the target application before finalizing procurement orders.

Pressure Sensors Transducers Selection Notes

Select this model when a ruggedized, high-accuracy pressure sensing solution is required for harsh industrial environments. The Microfused technology ensures long-term stability and reliability under varying thermal conditions. Ensure the system power supply matches the 5 VDC requirement and that the signal conditioning circuitry can accommodate the low-level millivolt output range effectively.

Pressure Sensors Transducers Part Context

This component belongs to the MS121 series of industrial pressure sensors from TE Connectivity / Measurement Specialties. The series is characterized by its durable Microfused design, which combines silicon sensing elements with stainless steel diaphragms. These sensors are engineered for demanding applications requiring precise pressure measurement and reliable operation over extended periods.

Pressure Sensors Transducers Replacement Considerations

Public confirmed substitute part numbers are not available in the provided source material.
