NPJ50AT6G30W-6dB

Overview

The NPJ50AT6G30W-6dB is an N-type in-line RF attenuator manufactured by TYCLON. It provides a fixed attenuation value of 6 dB with a nominal impedance of 50 Ohms. The device operates within a frequency range of 0 Hz to 6 GHz and supports a maximum power handling capacity of 30 Watts. It utilizes a straight connector configuration suitable for high-frequency applications.

Feature Summary

• Fixed 6 dB attenuation performance
• 50 Ohm impedance design
• N-Type connector interface
• Supports up to 30W power handling

Applications

• High-frequency signal measurement systems
• RF circuit testing environments
• Signal level adjustment in coaxial networks

Procurement Notes

Verify the specific part number NPJ50AT6G30W-6dB against official TYCLON documentation to confirm technical specifications. Ensure compatibility with existing N-type connectors and system impedance requirements before integration. Check RoHS2 compliance status if required for your project standards.

Selection Notes

Select this component when a fixed 6 dB reduction is required at frequencies up to 6 GHz. Consider the 30W power rating for high-power applications. Ensure the N-type interface matches the connected cables and equipment ports for proper mating.

Part Context

This model belongs to the TYCLON NPJ50AT series of coaxial attenuators. The series includes variants with different attenuation values, such as 3dB and 10dB options, all sharing similar N-type interfaces and 50 Ohm impedance characteristics for consistent system integration.

Replacement Considerations

Compatible substitutes include other N-type 50 Ohm attenuators with 6 dB attenuation and similar power ratings from TYCLON or other manufacturers, provided they meet the 6 GHz frequency limit and physical connector dimensions.
