P0469NL

$2.85

Description：CMC 11.6A 2LN SMD
Series：-
Mfr：Pulse Electronics
Package：Tube

SKU:a76e241aeb6e Category: Common Mode Chokes Brand: Pulse Electronics

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

P0469NL is listed in the Common Mode Chokes range at ChipApex. The manufacturer field lists Pulse Electronics. Its product description is CMC 11.6A 2LN SMD. Review the specifications below when checking this part for your BOM.

Common Mode Chokes specifications for P0469NL

Description：CMC 11.6A 2LN SMD
Series：-
Mfr：Pulse Electronics
Package：Tube
Filter Type：Power Line
Number of Lines：2
Current Rating (Max)：11.6A
DC Resistance (DCR) (Max)：10mOhm
Voltage Rating - DC：-
Voltage Rating - AC：-
Operating Temperature：-40°C ~ 120°C
Ratings：-
Approval Agency：-
Features：-
Mounting Type：Surface Mount
Size / Dimension：1.220" L x 1.000" W (30.99mm x 25.40mm)
Height (Max)：0.500" (12.70mm)
Package / Case：Horizontal, 4 PC Pad
Inductance @ Frequency：-
Impedance @ Frequency：-

Common Mode Chokes datasheet and documents for P0469NL

P0469NL

Common Mode Chokes Overview

The P0469NL is a surface-mount common mode choke manufactured by Pulse Electronics. It features a drum core design with an inductance of 630 µH and a rated current of 11.6 A. The component has a maximum DC resistance of 0.01 Ohms and a self-resonant frequency of 4.9 kHz. Its physical dimensions are 31 mm in length, 25.4 mm in width, and 12.7 mm in height.

Common Mode Chokes Feature Summary

Surface mount construction for automated PCB assembly
Drum core magnetic structure for efficient flux containment
High current handling capability suitable for power line filtering

Common Mode Chokes Applications

Power supply input filtering
EMI suppression on AC/DC lines
Common mode noise reduction in electronic equipment

Common Mode Chokes Procurement Notes

Verify the specific datasheet version to confirm mechanical tolerances and thermal characteristics. Ensure the mounting footprint matches the specified 31 mm x 25.4 mm dimensions. Check for any recent product change notices regarding material composition or manufacturing location updates.

Common Mode Chokes Selection Notes

Select this component when high current capacity is required alongside significant inductance values. The low DC resistance minimizes power loss in high-current applications. Consider the physical size constraints as the package is relatively large compared to standard SMD components.

Common Mode Chokes Part Context

This part belongs to the Pulse Electronics common mode choke portfolio designed for power line protection. It utilizes a shielded drum core architecture to manage electromagnetic interference effectively while maintaining structural integrity under high current loads.
