PA4344.823ANLT

$3.11

Description：FIXED IND 82UH 6.5A 83 MOHM SMD
Series：PA4344.XXXANLT
Mfr：Pulse Electronics
Package：Tape & Reel (TR),Cut Tape (CT)

SKU:cd52d68b6c4e Category: Fixed Inductors Brand: Pulse Electronics

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

PA4344.823ANLT is listed in the Fixed Inductors range at ChipApex. The manufacturer field lists Pulse Electronics. Its product description is FIXED IND 82UH 6.5A 83 MOHM SMD. Review the specifications below when checking this part for your BOM.

Fixed Inductors specifications for PA4344.823ANLT

Description：FIXED IND 82UH 6.5A 83 MOHM SMD
Series：PA4344.XXXANLT
Mfr：Pulse Electronics
Package：Tape & Reel (TR),Cut Tape (CT)
Type：Molded
Material - Core：-
Inductance：82 µH
Tolerance：±20%
Current Rating (Amps)：6.5 A
Current - Saturation (Isat)：8A
Shielding：Shielded
DC Resistance (DCR)：83mOhm Max
Q @ Freq：-
Frequency - Self Resonant：-
Ratings：AEC-Q200
Operating Temperature：-55°C ~ 155°C
Inductance Frequency - Test：100 kHz
Mounting Type：Surface Mount
Package / Case：Nonstandard
Supplier Device Package：-
Size / Dimension：0.701" L x 0.665" W (17.80mm x 16.90mm)
Height - Seated (Max)：0.276" (7.00mm)
Features：-

Fixed Inductors datasheet and documents for PA4344.823ANLT

PA4344.823ANLT

Fixed Inductors Overview

The PA4344.823ANLT is a shielded, molded surface-mount power inductor from Pulse Electronics. It features an inductance of 82 µH with a tolerance of ±20%. The component supports a maximum DC current of 6.5 A and a saturation current of 8 A. Its maximum DC resistance is 83 mΩ. The package dimensions are 18.3 mm x 17.2 mm x 7 mm. It operates within a temperature range of -55°C to +155°C and holds AEC-Q200 qualification.

Fixed Inductors Feature Summary

Shielded construction minimizes electromagnetic interference.
Molded core design enhances mechanical stability.
AEC-Q200 qualification ensures automotive reliability.

Fixed Inductors Applications

High current power supply circuits
Automotive electronic systems
DC-DC converter stages

Fixed Inductors Procurement Notes

Verify the specific suffix ANLT against official datasheets to confirm the exact electrical characteristics and packaging configuration. Ensure that the required operating temperature range and current ratings align with the system design specifications before finalizing procurement orders.

Fixed Inductors Selection Notes

Select this component for applications requiring high current handling and wide temperature operation. The 82 µH value suits filtering needs in medium-frequency switching converters. Consider the 7 mm height for board space constraints relative to lower-profile alternatives.

Fixed Inductors Part Context

This part belongs to the PA4344 series of high-power SMD inductors. It shares the same physical footprint and shielding technology as other variants in the family, differing primarily in inductance values and current ratings to suit various power delivery requirements.

Fixed Inductors Replacement Considerations

Direct substitutes include PA4344.103ANLT and PA4344.473ANLT from the same manufacturer series, which share identical package dimensions and mounting characteristics.
