PE-1008CD470JTT

$0.10

Description：FIXED IND 47NH 1A 80 MOHM SMD
Series：1008CD
Mfr：Pulse Electronics
Package：Tape & Reel (TR)

SKU:a51bf067e1f7 Category: Fixed Inductors Brand: Pulse Electronics

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

PE-1008CD470JTT is listed in the Fixed Inductors range at ChipApex. The manufacturer field lists Pulse Electronics. Its product description is FIXED IND 47NH 1A 80 MOHM SMD. Review the specifications below when checking this part for your BOM.

Fixed Inductors specifications for PE-1008CD470JTT

Description：FIXED IND 47NH 1A 80 MOHM SMD
Series：1008CD
Mfr：Pulse Electronics
Package：Tape & Reel (TR)
Type：Drum Core, Wirewound
Material - Core：Ceramic
Inductance：47 nH
Tolerance：±5%
Current Rating (Amps)：1:00 AM
Current - Saturation (Isat)：-
Shielding：Unshielded
DC Resistance (DCR)：80mOhm Max
Q @ Freq：65 @ 350MHz
Frequency - Self Resonant：1.2GHz
Ratings：-
Operating Temperature：-40°C ~ 125°C
Inductance Frequency - Test：50 MHz
Mounting Type：Surface Mount
Package / Case：1008 (2520 Metric)
Supplier Device Package：1008 (2520 Metric)
Size / Dimension：0.115" L x 0.110" W (2.92mm x 2.79mm)
Height - Seated (Max)：0.090" (2.29mm)
Features：-

Fixed Inductors datasheet and documents for PE-1008CD470JTT

PE-1008CD470JTT

Fixed Inductors Overview

The PE-1008CD470JTT is a fixed inductor from Pulse Electronics, designed for surface mount applications. It features an unshielded drum core and wirewound construction with a ceramic core material. The component has an inductance of 47 nH and a tolerance of ±5%. It supports a maximum DC current of 1 A with a maximum DC resistance of 80 mOhm. The self-resonant frequency is 1.2 GHz, and the Q factor is 65 at unspecified test conditions. It operates within a temperature range of -40°C to +125°C and is housed in a 1008 (2520 metric) package.

Fixed Inductors Feature Summary

Unshielded drum core wirewound design for high-frequency performance
Ceramic core material ensuring stable electrical characteristics
Surface mount packaging compatible with automated assembly

Fixed Inductors Applications

RF inductor circuits
High-frequency filtering applications
General purpose inductive components

Fixed Inductors Procurement Notes

Verify the specific manufacturer datasheet for the PE-1008CD470JTT to confirm all electrical parameters and mechanical dimensions prior to integration. Ensure that the selected component meets the required thermal and current specifications for the target application environment. Cross-reference official documentation to validate compliance with relevant regulatory standards such as RoHS and REACH requirements.

Fixed Inductors Selection Notes

Select this component based on its 47 nH inductance value and 1 A current rating suitable for RF and high-frequency designs. Consider the unshielded nature of the drum core when planning PCB layout to minimize electromagnetic interference with nearby traces. Verify that the 1008 package size fits within the available board space constraints and matches the intended manufacturing process capabilities.

Fixed Inductors Part Context

This part belongs to the CD series of general purpose inductors manufactured by Pulse Electronics. These components are characterized by their wirewound construction and ceramic cores, offering reliable performance in various electronic circuits. The series provides options for different inductance values and packages to suit diverse design requirements.
