PIC32MK0512GPG048-E/7MX

Microcontrollers Overview

The PIC32MK0512GPG048-E/7MX is a 32-bit microcontroller from the PIC32MK General Purpose and Motor Control family. It features a MIPS32 microAptiv core with an integrated Floating Point Unit, operating at frequencies up to 120 MHz. The device includes 512 KB of Flash program memory with Error Code Correction (ECC) and 64 KB of SRAM data memory. Key peripherals include a CAN FD module, seven 12-bit ADCs, nine motor control PWM pairs, and multiple communication interfaces such as SPI, I2C, and UART.

Microcontrollers Feature Summary

• Integrated MIPS32 microAptiv core with Floating Point Unit for high-performance arithmetic operations
• Dedicated motor control hardware including nine PWM pairs and Quadrature Encoder Interface modules
• Advanced analog subsystem featuring seven independent 12-bit ADCs and multiple op-amps/comparators
• Robust security and reliability mechanisms including ECC Flash and Fail-Safe Clock Monitor

Microcontrollers Applications

• Industrial motor drives and servo systems
• Automotive body electronics and powertrain control
• Smart energy metering and grid infrastructure
• Consumer appliances requiring precise motion control

Microcontrollers Procurement Notes

Verify the specific suffix codes against official Microchip documentation to confirm temperature range and package type. Ensure compatibility with existing PCB footprints for the TQFP-48 or VQFN-48 package. Confirm that the selected variant meets all functional safety requirements if applicable to your design.

Microcontrollers Selection Notes

Select this component when applications require a balance of processing power and specialized motor control peripherals. The inclusion of ECC Flash ensures data integrity for critical code storage. Consider the pin count and available I/O resources relative to system connectivity needs before finalizing the part number.

Microcontrollers Part Context

This device belongs to the PIC32MK GPG/MCJ family, designed for general-purpose and motor control applications. It shares architectural similarities with other PIC32MK devices but offers specific peripheral configurations optimized for efficiency and performance in embedded control environments.

Microcontrollers Replacement Considerations

Consult Microchip's official cross-reference tools for verified compatible parts. Direct replacements must match the core architecture, memory size, and peripheral set to ensure software compatibility.
