PM40-R27M

$0.52

Description：FIXED IND 270NH 450MA 360MOHM SM
Series：PM40
Mfr：Bourns Inc.
Package：Tape & Reel (TR)

SKU:85b1348ebf94 Category: Fixed Inductors Brand: Bourns Inc.

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

PM40-R27M is listed in the Fixed Inductors range at ChipApex. The manufacturer field lists Bourns Inc.. Its product description is FIXED IND 270NH 450MA 360MOHM SM. Review the specifications below when checking this part for your BOM.

Fixed Inductors specifications for PM40-R27M

Description：FIXED IND 270NH 450MA 360MOHM SM
Series：PM40
Mfr：Bourns Inc.
Package：Tape & Reel (TR)
Type：Molded
Material - Core：Non-Magnetic
Inductance：270 nH
Tolerance：±20%
Current Rating (Amps)：450 mA
Current - Saturation (Isat)：-
Shielding：Unshielded
DC Resistance (DCR)：360mOhm Max
Q @ Freq：30 @ 25.2MHz
Frequency - Self Resonant：320MHz
Ratings：-
Operating Temperature：-55°C ~ 125°C
Inductance Frequency - Test：25.2 MHz
Mounting Type：Surface Mount
Package / Case：1812 (4532 Metric)
Supplier Device Package：1812
Size / Dimension：0.177" L x 0.126" W (4.50mm x 3.20mm)
Height - Seated (Max)：0.126" (3.20mm)

Fixed Inductors datasheet and documents for PM40-R27M

PM40-R27M

Fixed Inductors Overview

The Bourns PM40-R27M is a fixed surface-mount inductor with an inductance of 270 nH and a tolerance of ±20%. It features a maximum DC current rating of 450 mA and a maximum DC resistance of 360 mOhms. The component utilizes a molded, unshielded design suitable for PCB mounting. It operates within a standard temperature range and is packaged in an 1812 footprint.

Fixed Inductors Feature Summary

Fixed inductance value of 270 nH with ±20% tolerance
Surface-mount construction with a molded body
Unshielded magnetic design to minimize interference

Fixed Inductors Applications

RF signal filtering circuits
Impedance matching networks
General-purpose RF chokes

Fixed Inductors Procurement Notes

Verify the specific package dimensions and termination style against the official datasheet to ensure compatibility with your PCB layout. Confirm that the 450 mA current rating meets your circuit's peak and continuous load requirements. Check for any RoHS compliance documentation if required by your manufacturing standards.

Fixed Inductors Selection Notes

Select this component when a low-inductance, high-frequency solution is required. The unshielded design may necessitate careful placement to avoid coupling with nearby traces. Ensure the operating environment stays within the specified thermal limits and that the 360 mOhms resistance does not cause excessive voltage drop or power loss in the application.

Fixed Inductors Part Context

This part belongs to the Bourns PM40 series of SMD inductors. The series offers various inductance values tailored for RF applications. The manufacturer provides ECAD models to assist in schematic and layout integration. This specific model represents a low-value option within the broader product line.
