PT2S7RC4

PT2S7RC4 is listed in the Power Relays, Over 2 Amps range at ChipApex. The manufacturer field lists TE Connectivity Potter & Brumfield Relays. Its product description is RELAY GEN PURPOSE DPDT 12A 24V. Review the specifications below when checking this part for your BOM.

Power Relays, Over 2 Amps specifications for PT2S7RC4

• Description：RELAY GEN PURPOSE DPDT 12A 24V
• Series：PT, SCHRACK
• Mfr：TE Connectivity Potter & Brumfield Relays
• Package：Bulk
• Mounting Type：DIN Rail
• Coil Voltage：24VAC
• Contact Form：DPDT (2 Form C)
• Contact Rating (Current)：12:00 AM
• Switching Voltage：400VAC - Max
• Load - Max Switching：4800VA
• Coil Current：125 mA
• Coil Type：Non Latching
• Features：Lighted Indicator, Mechanical Indicator, Socket Included, Test Button
• Termination Style：Screw Terminal
• Seal Rating：-
• Coil Insulation：Class F
• Must Operate Voltage：19.2 VAC
• Must Release Voltage：7.2 VAC
• Operating Temperature：-40°C ~ 70°C
• Contact Material：Silver Nickel (AgNi)
• Approval Agency：cURus, VDE
• Relay Type：General Purpose
• Grade：-
• Qualification：-
• Operate Time：-
• Release Time：-

Power Relays, Over 2 Amps datasheet and documents for PT2S7RC4
