RTD34005F

RTD34005F is listed in the Power Relays, Over 2 Amps range at ChipApex. The manufacturer field lists TE Connectivity Potter & Brumfield Relays. Its product description is RELAY GEN PURPOSE SPST 16A 5V. Review the specifications below when checking this part for your BOM.

Power Relays, Over 2 Amps specifications for RTD34005F

• Description：RELAY GEN PURPOSE SPST 16A 5V
• Series：RT1
• Mfr：TE Connectivity Potter & Brumfield Relays
• Package：Bulk
• Mounting Type：Through Hole
• Coil Voltage：5VDC
• Contact Form：SPST-NO (1 Form A)
• Contact Rating (Current)：16 A
• Switching Voltage：400VAC - Max
• Load - Max Switching：6400VA
• Coil Current：80.6 mA
• Coil Type：Non Latching
• Features：-
• Termination Style：PC Pin
• Seal Rating：Sealed - Fully
• Coil Insulation：Class F
• Must Operate Voltage：3.5 VDC
• Must Release Voltage：0.5 VDC
• Operating Temperature：-40°C ~ 85°C
• Contact Material：Silver Nickel (AgNi)
• Approval Agency：CQC, CSA, cURus, VDE
• Relay Type：General Purpose
• Grade：-
• Qualification：-
• Operate Time：8 ms
• Release Time：6 ms

Power Relays, Over 2 Amps datasheet and documents for RTD34005F
