SL 19 132 2 S

Headers, Male Pins Overview

The Fischer Elektronik SL 19 132 2 S is a PCB male header connector featuring a 2.54 mm pitch and two rows of contacts. It utilizes CuSn-alloy contacts with gold plating for reliable signal transmission. The component is designed for through-hole mounting on printed circuit boards, offering a straight configuration suitable for board-to-board or wire-to-board interconnections. Its construction supports standard industrial environments with robust mechanical stability.

Headers, Male Pins Feature Summary

• Gold-plated copper tin alloy contacts ensure corrosion resistance and stable electrical performance
• Two-row straight pin header design facilitates compact vertical integration
• Through-hole soldering method provides secure mechanical attachment to PCBs

Headers, Male Pins Applications

• Board-to-board interconnection systems
• Wire-to-board assembly applications
• General electronic equipment manufacturing

Headers, Male Pins Procurement Notes

Verify the specific contact count and row configuration against project requirements before ordering. Confirm that the through-hole mounting style matches the target PCB layout. Ensure the gold-plated contact material meets the environmental durability standards required for the intended application environment. Cross-reference the datasheet dimensions to validate spatial constraints within the final assembly.

Headers, Male Pins Selection Notes

Choose this connector when a low-profile, two-row male header is needed for direct PCB insertion. The gold-plated contacts are suitable for applications requiring high reliability and resistance to oxidation. Consider the straight orientation for vertical mating connections. Evaluate the mechanical strength provided by the through-hole termination against vibration or stress conditions in the operational environment.

Headers, Male Pins Part Context

This component belongs to the Fischer Elektronik SL 19 series of PCB connectors. The series offers various pole counts and configurations to support diverse electronic design needs. As a male header, it serves as the counterpart to female sockets or jacks, enabling modular connectivity solutions in consumer and industrial electronics assemblies.

Headers, Male Pins Replacement Considerations

Compatible substitutes include other Fischer Elektronik headers from the SL 19 series with matching 2.54 mm pitch and two-row geometry. Verify that alternative parts maintain the same gold-plated contact surface treatment and through-hole mounting characteristics to ensure functional equivalence.
