SL 5 097 8 S

$0.81

Description：ONE ROW, 0.635 MM STRO
Series：SL 5 097
Mfr：Fischer Elektronik
Package：Bulk

SKU:bc87ea00b9af Category: Headers, Male Pins Brand: Fischer Elektronik

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

SL 5 097 8 S is listed in the Headers, Male Pins range at ChipApex. The manufacturer field lists Fischer Elektronik. Its product description is ONE ROW, 0.635 MM STRO. Review the specifications below when checking this part for your BOM.

Headers, Male Pins specifications for SL 5 097 8 S

Description：ONE ROW, 0.635 MM STRO
Series：SL 5 097
Mfr：Fischer Elektronik
Package：Bulk
Connector Type：Header
Contact Type：Male Pin
Pitch - Mating：0.100" (2.54mm)
Number of Positions：8
Number of Rows：1
Row Spacing - Mating：-
Number of Positions Loaded：All
Style：Board to Board or Cable
Shrouding：Unshrouded
Mounting Type：Through Hole
Termination：Solder
Fastening Type：Push-Pull
Contact Length - Mating：0.236" (6.00mm)
Contact Length - Post：0.130" (3.30mm)
Overall Contact Length：0.748" (19.00mm)
Insulation Height：0.110" (2.79mm)
Contact Shape：Square
Contact Finish - Mating：Gold
Contact Finish Thickness - Mating：7.87µin (0.200µm)
Contact Finish - Post：Tin
Contact Material：Copper Tin
Insulation Material：Polyamide (PA46), Nylon 4/6, Glass Filled
Features：-
Operating Temperature：-40°C ~ 163°C
Material Flammability Rating：UL94 V-0
Insulation Color：Black
Current Rating (Amps)：3A
Voltage Rating：250VAC

Headers, Male Pins datasheet and documents for SL 5 097 8 S

SL 5 097 8 S

Headers, Male Pins Overview

The SL 5 097 8 S is a single-row pin header connector manufactured by Fischer Elektronik. It features eight positions with a 2.54 mm pitch, designed for through-hole mounting on printed circuit boards. The component utilizes copper-tin contacts with tin plating to ensure reliable electrical connections. Its physical dimensions include an insertion depth of 3.30 mm into the PCB and a total contact length of 13.90 mm. The housing is constructed from polyamide (PA46), providing structural integrity and insulation.

Headers, Male Pins Feature Summary

Single-row configuration with square contact shape for standard board stacking
Through-hole termination method compatible with automated assembly processes
Tin-plated copper-tin contacts ensuring corrosion resistance and conductivity

Headers, Male Pins Applications

General electronic interconnects in consumer devices
Industrial control panel wiring
Communication equipment signal routing

Headers, Male Pins Procurement Notes

Verify that the specific ordering suffix matches the required contact plating and row count. Confirm that the thermal rating aligns with the application's soldering profile requirements. Ensure the housing material specification meets the environmental conditions of the final assembly. Cross-reference the manufacturer datasheet for precise dimensional tolerances before integration.

Headers, Male Pins Selection Notes

Select this component when a low-profile, single-row header is required for direct PCB mounting. The 2.54 mm pitch ensures compatibility with standard ribbon cables and mating connectors. Consider the tin plating for cost-effective applications where high corrosion resistance is not critical. Evaluate the mechanical stability provided by the polyamide housing for vibration-prone environments.

Headers, Male Pins Part Context

This part belongs to the Fischer Elektronik SL series, which specializes in pin headers and socket connectors. The series offers various configurations to meet diverse connectivity needs in the electronics industry. Fischer Elektronik focuses on producing high-quality components with strict adherence to quality standards, ensuring reliability across various industrial and commercial applications.
