SL 5 525 33 Z

Headers, Male Pins Overview

The SL 5 525 33 Z is a single-row male pin header connector manufactured by Fischer Elektronik. It features 33 positions with a 0.100-inch (2.54 mm) pitch, designed for through-hole mounting on printed circuit boards. The contacts are constructed from copper alloy and finished with a tin plating to ensure reliable electrical conductivity and corrosion resistance. The connector utilizes PA46 (polyamide) insulation material, which provides mechanical stability and thermal endurance suitable for standard soldering processes. This component serves as a straight board-to-board or wire-to-board interconnection solution in electronic assemblies requiring robust signal transmission.

Headers, Male Pins Feature Summary

• Single-row configuration with 33 male pins for direct PCB insertion
• Tin-plated copper alloy contacts ensuring stable electrical performance
• PA46 polyamide insulation offering high thermal stability

Headers, Male Pins Applications

• Board-to-board interconnections in stacked PCB architectures
• Wire-to-board connections for signal routing
• General electronic assembly interconnects requiring through-hole mounting

Headers, Male Pins Procurement Notes

Verify the specific suffix 'Z' against the manufacturer's official datasheet to confirm contact length and plating specifications. Ensure the ordering part number matches the required pin count and row configuration. Cross-reference the insulation material rating with your application's thermal requirements before procurement.

Headers, Male Pins Selection Notes

Select this component when a single-row, 33-position male header with 2.54 mm spacing is required. Consider the through-hole mounting style and tin-plated contact finish for compatibility with standard soldering profiles. Verify that the straight orientation fits the mechanical constraints of the assembly.

Headers, Male Pins Part Context

This part belongs to the SL 5 series of Fischer Elektronik connectors, which are characterized by their precision engineering and reliability in electronic interconnections. The series typically offers various pin counts and configurations to suit different density requirements while maintaining consistent electrical and mechanical standards across the product line.

Headers, Male Pins Replacement Considerations

Consult Fischer Elektronik's official substitution guide for compatible alternatives. Generic headers may differ in contact material, insulation grade, or dimensional tolerances, potentially affecting performance.
